MAXIM MAX1920/MAX1921 handbook

Update: 28 September, 2023

The MAX1921 evaluation kit provides a fixed 1.8V output voltage from a 2V to 5.5V input source and delivers up to 400mA output current. It is a step-down switching regulator with an internal power switch and synchronous rectifier in a tiny SOT23 package. The MAX1921 EV kit is a fully assembled and tested surface-mount circuit board. It can also be used to evaluate other fixed-output voltage versions of the MAX1921 or the MAX1920, which is a step-down switching regulator with an adjustable output voltage.

Brand: MAXIM

File format: PDF

Size: 92 KB

MD5 Checksum: 387E859DE59EF9835673689F452FF0DF

Publication date: 08 June, 2012

Downloads: -

PDF Link: MAXIM MAX1920/MAX1921 handbook PDF

Download
