panasonic Silicon NPN epitaxial planer transistor XN06211 (XN6211) handbook

Update: 28 September, 2023

This document describes the features and characteristics of Composite Transistors XN06211 (XN6211), which is a silicon NPN epitaxial planar transistor for switching/digital circuits. The product incorporates two elements into one package, reducing the mounting area and assembly cost. The document also provides the absolute maximum ratings and electrical characteristics of the product.

Brand: Panasonic

File format: PDF

Size: 75 KB

MD5 Checksum: 5C2D190E4462A3C61FDEFA4E525787FF

Publication date: 08 June, 2012

Downloads: -

PDF Link: panasonic Silicon NPN epitaxial planer transistor XN06211 (XN6211) handbook PDF

Download
