ANALOG DEVICES ADV7189B handbook(1)

Update: 30 September, 2023

The product is a multi-format video decoder that supports NTSC-(J, M, 4.43), PAL-(B/D/G/H/I/M/N), SECAM formats. It integrates three 54 MHz, Noise Shaped Video®, 12-bit ADCs, clocked from a single 28 MHz crystal. It has Adaptive-Digital-Line-Length-Tracking (ADLLT™), signal processing, and enhanced FIFO management functions, which can lock to weak, noisy, and unstable video sources (such as VCRs and tuners) and provide subcarrier frequency lock and status information output.

---
