FAIRCHILD DM74ALS520 DM74ALS521 8-Bit Comparator handbook

Update: 30 September, 2023

DM74ALS520/DM74ALS521 are two 8-bit comparators, can compare two 8-bit data with “equal to” function. Both comparators can be enabled externally, and have single-ended outputs. DM74ALS520 also provides pull-up resistors for B input for analog or switch data.


File format: PDF

Size: -

MD5 Checksum: FD107805F1697153D2D9491CF157050B

Publication date: 07 June, 2012

Downloads: -

PDF Link: FAIRCHILD DM74ALS520 DM74ALS521 8-Bit Comparator handbook PDF
