ANALOG DEVICES AD1958 datasheet

Update: 01 October, 2023

The AD1958 is an Analog Devices 5V stereo audio DAC system that accepts 16-/18-/20-/24-Bit data, supports 24 Bits, 192 kHz sample rate, and accepts a wide range of sample rates, including 32 kHz, 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz and 192 kHz. It features a multibit Sigma-Delta modulator with “Perfect Differential Linearity Restoration” for reduced idle tones and noise floor, Data Directed Scrambling DAC—Least Sensitive to Jitter, Single-Ended Output for Easy Use, and Signal-to-Noise (Not Muted) at 48 kHz Sample Rate (A-Weighted Stereo) 109 dB.

Brand: ANALOG

File format: PDF

Size: 126 KB

MD5 Checksum: 46C9F89065A19F51FBBF3B52CA0C2D3C

Publication date: 07 June, 2012

Downloads: -

PDF Link: ANALOG DEVICES AD1958 datasheet PDF

Download
