MOTOROLA MCCF33094 Manual

Update: 28 September, 2023

The document introduces a chip for automotive ignition applications. It provides outstanding control of the ignition coil when used with an appropriate Motorola Power Darlington Transistor. Engine control systems utilizing the MCCF33094 exhibit exceptional fuel efficiency and low exhaust emissions. For proper operation, the MCCF33094 requires a single Hall Sensor input signal, which is compared to an accurate internal reference. The MCCF33094 utilizes Flip-Chip Technology in which solder bumps, rather than traditional wire bonds, are created to establish mechanical and electrical contact to the chip. This process affords a unique device having improved reliability at elevated operating temperatures.

Brand: MOTOROLA

File format: PDF

Size: 51 KB

MD5 Checksum: 5C3AF840FB56E5D4C339BF6230A7FF8C

Publication date: 06 June, 2012

Downloads: -

PDF Link: MOTOROLA MCCF33094 Manual PDF

Download
