Panasonic XN01601 (XN1601) handbook

Update: 30 September, 2023

XN01601 is a composite transistor from Toshiba. It consists of a silicon PNP epitaxial planer transistor (Tr1) and a silicon NPN epitaxial planer transistor (Tr2). XN01601 has two elements incorporated into one package (emitter-coupled transistors), which reduces the mounting area and assembly cost by half.

Brand: Panasonic

File format: PDF

Size: 86 KB

MD5 Checksum: 69820BAAD74138242DCD801C1047E69D

Publication date: 06 June, 2012

Downloads: -

PDF Link: Panasonic XN01601 (XN1601) handbook PDF

Download
