LINEAR Step-Down Module Regulator Produces 15A Output from Inputs Down to 1.5V No Bias Supply Required 1.5V to 5.5V Input 0.8V to 5V Output from a 15mm × 15mm × 4.32mm LGA
Update: 30 September, 2023
The LTM4611 is a switch mode, step-down DC/DC µModule® regulator in a compact 15mm × 15mm × 4.32mm LGA surface mount package. The switching controller, MOSFETs, inductor and supporting components are housed in the package. With a built-in differential remote sense amplifier, the LTM4611 can tightly regulate its output voltage from 0.8V to within 300mV of VIN and deliver 15A output efficiently from 1.5V to 5.5V input.
File format: PDF
Size: -
MD5 Checksum: F318C0CD72212B6AD3B71DAFCB87AE54
Publication date: 05 June, 2012
Downloads: -
PDF Link:
LINEAR Step-Down Module Regulator Produces 15A Output from Inputs Down to 1.5V No Bias Supply Required 1.5V to 5.5V Input 0.8V to 5V Output from a 15mm × 15mm × 4.32mm LGA PDF
