PHOENIX CONTACT - SMKDS 1/ 2-3 5 handbook

Update: 30 September, 2023

This is a PC terminal block product named SMKDS 1/ 2-3,5 from PHOENIX CONTACT. The rated current is 10 A, the rated voltage is 160 V, the pin spacing is 3.5 mm, there are 2 pins, the connection type is screw connection, the assembly is soldering, the conductor/PCB connection direction is 55 ° and the color is green.


File format: PDF

Size: -

MD5 Checksum: F0C1746ABA998DB54A108B345ED7BE0F

Publication date: 11 May, 2012

Downloads: -

PDF Link: PHOENIX CONTACT - SMKDS 1/ 2-3 5 handbook PDF
