Key facts
- Manuals
- 6
- Languages
- ZH
- Last added
- 2011-12-30
Featured 青岛泰润电子 manuals
Trions TMCWQ Series Non-Contact Angle Sensor Manual
The TMCWQ series non‑contact angle sensor from Trions converts mechanical rotation into standard electrical signals (4‑20 mA, 0‑5 V, 0‑10 V, 1‑5 V, etc.) for automotive electrical systems. It offers high reliability, small temperature drift, high resolution and linearity, and can replace Honeywell RPN rotary position sensors.
The manual details product features, technical parameters, wiring options (plug or shielded cable), zero‑adjustment procedure, installation precautions, and typical output curves. Customizable measurement ranges and output formats are supported to meet specific customer requirements. This manual is written in Chinese.
Covers: Product Introduction · Product Features · Application Fields · Model Description · Physical Dimensions · Typical Output Curve
Trions TMCW0 Axis Series Non-contact Angle Sensor Manual
The TMCW0 series is a non‑contact angle sensor that uses an integrated magnetic‑resistive chip to convert mechanical rotation into standard analog signals such as 4‑20 mA, 0‑5 V, 0‑10 V or 1‑5 V. The sensor consists of a separate signal pickup unit and a magnetic sensitive body, allowing a fully sealed, IP67‑rated design suitable for harsh environments.
Installation requires fixing the sensitive body, aligning the pickup unit with the body axis, and adjusting the unit until the output signal reaches its midpoint (e.g., 12 mA for 4‑20 mA). The manual also provides selection guidelines, technical parameters, and usage precautions to ensure accurate angle measurement. This manual is written in Chinese.
Covers: Product Introduction · Product Features · Application Fields · Selection Guide · Technical Parameters · Installation and Zeroing
Trions TMS10 Series Differential Magnetic Resistance Sensor Manual
The TMS10 series differential magnetic resistance sensor from Trions offers a compact metal housing, high sensitivity, and strong anti‑interference performance. It detects magnetic fields generated by ferromagnetic objects or shafts, producing a voltage output proportional to the magnetic field change.
Typical applications include speed measurement of gears and rotors, angle detection, and small linear displacement measurement. The manual details installation, electrical connections, operating voltage limits, temperature range, and handling precautions. This manual is written in Chinese.
Covers: Product Features · Typical Applications · Technical Parameters · Installation and Wiring · Usage Precautions
Trions TMS8 Series Differential Magnetic Resistance Sensor Manual
The manual describes the TMS8 series differential magnetic resistance sensor produced by Trions (Qingdao Trions Electronics Technology Co., Ltd.). It outlines product features such as wide speed range, non‑contact measurement, high sensitivity, and robust metal housing.
Typical applications include speed detection for spindles, PCB drilling machines, and small linear displacement measurement. The document also lists technical parameters, dimensions, and important usage precautions to ensure reliable operation. This manual is written in Chinese.
Covers: Product Features · Typical Applications · Working Principle · Model Explanation · Dimensions · Technical Parameters
Latest 青岛泰润电子 manuals
Trions TMCWQ Series Non-Contact Angle Sensor Manual
User Manual 4 pages · 146 KB · ZHThe Trions TMCWQ series non‑contact angle sensor manual provides specifications, wiring, installation and usage instructions for automotive applications.
Trions TMCW0 Axis Series Non-contact Angle Sensor Manual
User Manual 4 pages · 144 KB · ZHThe manual describes features, specifications, installation and zeroing procedures for the Trions TMCW0 non‑contact angle sensor.
Qingdao Temujin Electronic technology TZDM series Screw thread Type Vibration sensor Manual
Trions TMS10 Series Differential Magnetic Resistance Sensor Manual
User Manual 4 pages · 200 KB · ZHThe Trions TMS10 series differential magnetic resistance sensor manual provides specifications, wiring, and application guidance.
Trions TMS8 Series Differential Magnetic Resistance Sensor Manual
User Manual 4 pages · 184 KB · ZHThe Trions TMS8 series differential magnetic resistance sensor manual provides specifications, typical applications, and usage guidelines.
Trions TQXJ-S Series Tilt Angle Sensor Manual
User Manual 2 pages · 155 KB · ZHThe Trions TQXJ‑S series tilt angle sensor manual provides specifications, installation instructions, and application guidance.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in 青岛泰润电子 manuals
What are the wiring pin assignments for the sensor?
Pin 1 is ground, Pin 2 is the positive supply, and Pin 3 is the signal line.
How is the zero point of the sensor adjusted?
Secure the sensor, connect it correctly, power it on, measure the output voltage or current to ground, and rotate the shaft until the output reads zero (e.g., 2.5 V for 0‑5 V output).
What temperature range can the TMS10 sensor operate in?
It operates safely between –30 °C and +70 °C.
From: Trions TMS10 Series Differential Magnetic Resistance Sensor Manual
What precautions should be taken when handling the sensor surface?
The sensing surface must not be squeezed, collided with, or scratched to avoid damage.
From: Trions TMS10 Series Differential Magnetic Resistance Sensor Manual
What is the operating temperature range of the TMS8 sensor?
The sensor can operate from –30 °C to 70 °C.
From: Trions TMS8 Series Differential Magnetic Resistance Sensor Manual
What is the maximum supply voltage allowed for the sensor?
The maximum supply voltage is 10 V DC.
From: Trions TMS8 Series Differential Magnetic Resistance Sensor Manual
