Featured uni manuals
CV C47 Camera User Manual
This manual introduces the CV C47 digital camera, describing its main features such as a 1600 × 1200 sensor, SD card support up to 256 MB, USB 1.1 interface, and built‑in rechargeable battery. It also lists compatible operating systems and included accessories.
The guide covers basic operation (power on, inserting SD card and batteries), photo capture, selfie mode, video recording, playback of photos and videos, audio recording and playback, as well as charging procedures and quick‑start tips for using the camera as a PC webcam. This manual is written in Chinese.
Covers: Introduction · Basic Operation · Photo Capture · Selfie Mode · Video Recording · Playback
UN CAM1 3.7 Quick Application Guide
This guide introduces the UN CAM1 3.7 digital camera, a compact device that combines photo, video, audio recording and PC‑camera functions. It outlines the main hardware features such as a 1600 × 1200 pixel sensor, SD‑card storage, USB 1.1 interface and built‑in speaker.
The document provides step‑by‑step instructions for inserting the SD card, powering on the camera, taking photos, selfies, video recording, playback, audio recording, video output to a TV, software installation on a PC, and battery charging using the built‑in automatic charger. This manual is written in Chinese.
Covers: Introduction · Identifying the Camera · Basic Operation · Playback · Video Output · Software Installation and Use
Latest uni manuals
UNi MID-54419 handbook
MID-54419 is a photo diode produced by Unity Opto Technology Co., Ltd., which has high photo sensitivity, low junction capacitance, high cut-off frequency, fast switching time and 40° acceptance angle.
UNi MVL-591G handbook
This document is about the specifications of MVL-591G LED lamp, including the product's size, power, current, voltage and other parameters.
UNI MIM-0KM2ASF DATA SHEET
The MIM-0KM2ASF SERIES is miniaturized infrared receivers for remote control and other appplications requiring improved ambient light rejection. The separate PIN diode and preamplifier IC are assembled on a single leadframe. The epoxy package contains a special IR filter. This module has excellent performance even in disturbed ambient light applications and provides protection against uncontrolled output pulses.
UNi UVP-3X57 SERIES 5X7 DOT MATRIX LED DISPLAY handbook
The UVP-3X57 series is a 3.0 inch (76.2mm) height 5X7 dot matrix display. Single color displays have the choices of three bright colors - AlGaAs red/green/red orange. Multicolor displays are applicable to two colors: green and red orange. All devices have a gray face and white dot. The AlGaAs red LED chips are made from AlGaAs on a non-transparent GaAs substrate. The green LED chips are made from GaP on a transparent GaP substrate. The red orange LED chips are made from GaAsP on a transparent GaP substrate.
uni GaAs HIGH POWER T-1 3/4 PACKAGE INFRARED EMITTING DIODE MIE-544A4
MIE-544A4 is a infrared emitting diode from Unity Opto Technology Co., Ltd. It uses GaAs chip and has high radiant power and high radiant intensity. It is suitable for DC and high pulse current operation. It has a standard T-1 3/4 (φ5mm) package with a radiant angle of 40° and a peak wavelength of λP =940 nm. It has good spectral matching to si-photodetector.
UNI URC105 MANUAL
CV C47 Camera User Manual
User Manual 7 pages · 482 KB · ZHThe CV C47 camera user manual provides step‑by‑step operating instructions, basic functions, playback, recording, and charging details.
UN CAM1 3.7 Quick Application Guide
Quick Start Guide 7 pages · 357 KB · ZHA quick application guide for the UN CAM1 3.7 digital camera covering basic operation, playback, video output and charging.
UNI 800B quantify Scales controller Manual
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Quick Start Guide
The shortest path to a working setup, usually only a few pages.
Questions answered in uni manuals
How do I take a photo with the CV C47 camera?
Insert the SD card and batteries, power on the camera, set the desired direction, then press the shutter button to capture the image.
How do I charge the camera’s battery?
Connect the camera to a USB power source or an appropriate power adapter; the charging indicator will show a slow pulse, and charging completes when the indicator slows further.
How do I insert an SD card into the camera?
Insert the SD card with the correct orientation into the slot, then slide the lock and close the battery compartment door.
How can I start the selfie mode?
Enter the menu, select “启动自拍”, and press the shutter button; the front selfie indicator will flash and a photo will be taken after 10 seconds.
