Key facts
- Manuals
- 5
- Languages
- EN
- Last added
- 2026-10-03
Featured Ubiquiti manuals
Ubiquiti USG UniFi Security Gateway Quick Start Guide
The Quick Start Guide provides essential information for setting up the Ubiquiti UniFi Security Gateway (USG), a gigabit Ethernet router that is part of the UniFi Enterprise System. It includes package contents, hardware overview, mounting instructions, power and network connections, and software installation steps.
Key sections cover hardware installation (wall‑mounting and clearance), power connection, Ethernet port setup, resetting to factory defaults, and detailed specifications such as dimensions, processor, memory, power consumption, and compliance markings.
Covers: Introduction · Package Contents · Hardware Overview · Hardware Installation · Connecting Power · Network Connections
Ubiquiti NanoStation M5 5GHz Hi Power 2x2 MIMO AirMax TDMA Station Datasheet
The NanoStation M5 is a high‑power 5 GHz outdoor wireless station featuring a built‑in 2×2 MIMO antenna and AirMax TDMA protocol for long‑range point‑to‑point links. It is designed for outdoor deployment with UV‑stabilized plastic housing and optional pole‑mount kit.
Key specifications include a 400 MHz Atheros MIPS 24KC processor, 32 MB SDRAM, 8 MB flash, dual 10/100 BASE‑TX Ethernet ports, operating frequency 5470‑5825 MHz, TX power up to 27 dBm, antenna gain 14.6‑16.1 dBi, and power over Ethernet (15 V, 0.8 A) with a maximum consumption of 8 W.
Covers: Technical Specs/Datasheet · System Information · Processor Specs · Memory Information · Networking Interface · Operating Frequency
Ubiquiti NanoStation M2 2.4GHz Hi‑Power 2x2 MIMO AirMax TDMA Station Datasheet
The NanoStation M2 is a high‑power 2.4 GHz outdoor wireless station featuring a built‑in 2×2 MIMO antenna and Ubiquiti's AirMax TDMA protocol. It is designed for long‑range point‑to‑point and point‑to‑multipoint links and includes a passive Power‑over‑Ethernet (PoE) power method.
Key specifications include a frequency range of 2.32‑2.55 GHz, maximum gain of 10.4‑11.2 dBi, max VSWR 1.6:1, operating temperature from –30 °C to +80 °C, enclosure size 29.4 cm × 8 cm × 3 cm, weight 0.4 kg, and a 24 V/0.5 A surge‑protected PoE supply. The device provides two 10/100 BASE‑TX Ethernet ports and is powered by a 400 MHz Atheros MIPS 24KC processor with 32 MB SDRAM and 8 MB flash memory.
Covers: Data Rate and Sensitivity · Frequency Range and VSWR · Antenna Gain and Beamwidth · Power Supply and Consumption · Operating Temperature and Humidity · Enclosure Size and Weight
Ubiquiti NanoStation 5 Datasheet
The NanoStation 5 is an outdoor 5 GHz wireless bridge designed for long‑range point‑to‑point links. It features a dual‑polarized adaptive antenna and supports 802.11a OFDM with selectable channel widths of 5, 10, 20, and 40 MHz.
Key specifications include data rates from 6 Mbps to 54 Mbps with up to 24 dBm transmit power, sensitivity down to –94 dBm, a 14 dBi antenna gain, and a compact enclosure measuring 26.4 cm × 8 cm × 3 cm. The unit operates from –20 °C to +70 °C, consumes a maximum of 5 W, and is powered via 12 V / 1 A PoE. It is equipped with an Atheros AR2313 SOC (180 MHz) and 16 MB SDRAM plus 4 MB flash storage.
Covers: Data Rate and Sensitivity · Enclosure Characteristics · Power and Power Supply · Antenna and Polarization · Processor and Memory · Regulatory / Compliance
Latest Ubiquiti manuals
Ubiquiti USG UniFi Security Gateway Quick Start Guide
Quick Start Guide 24 pages · 4.4 MB · ENQuick start guide for the Ubiquiti UniFi Security Gateway (USG) covering package contents, installation, and software setup.
Ubiquiti NanoStation M5 5GHz Hi Power 2x2 MIMO AirMax TDMA Station Datasheet
Datasheet 1 pages · 244 KB · ENTechnical specifications for the Ubiquiti NanoStation M5 5 GHz Hi‑Power 2×2 MIMO AirMax TDMA wireless station.
Ubiquiti NanoStation M2 2.4GHz Hi‑Power 2x2 MIMO AirMax TDMA Station Datasheet
Datasheet 1 pages · 275 KB · ENThe Ubiquiti NanoStation M2 is a 2.4 GHz outdoor wireless device with 2×2 MIMO, AirMax TDMA and detailed technical specifications.
Ubiquiti NanoStation 5 Datasheet
Datasheet 2 pages · 413 KB · ENThe Ubiquiti NanoStation 5 datasheet provides technical specifications, performance data, and regulatory information for the outdoor wireless device.
Ubiquiti NanoStation2 Datasheet
Datasheet 2 pages · 417 KB · ENThe NanoStation2 datasheet lists technical specifications, dimensions, power requirements, wireless performance and regulatory compliance.
Which document do I need?
Quick Start Guide
The shortest path to a working setup, usually only a few pages.
Datasheet
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in Ubiquiti manuals
What is the default network setting for the LAN port?
The LAN port is set to DHCP Server by default.
How do you reset the UniFi Security Gateway to factory defaults?
Press and hold the Reset button for about 10 seconds until the right LED on the VOIP port starts flashing and then becomes solid.
What frequency range does the NanoStation M5 operate in?
It operates from 5470 MHz to 5825 MHz.
From: Ubiquiti NanoStation M5 5GHz Hi Power 2x2 MIMO AirMax TDMA Station Datasheet
How is the NanoStation M5 powered?
It uses passive Power over Ethernet with a 15 V, 0.8 A integrated POE adapter.
From: Ubiquiti NanoStation M5 5GHz Hi Power 2x2 MIMO AirMax TDMA Station Datasheet
What is the operating frequency range of the NanoStation M2?
The NanoStation M2 operates from 2.32 GHz to 2.55 GHz.
From: Ubiquiti NanoStation M2 2.4GHz Hi‑Power 2x2 MIMO AirMax TDMA Station Datasheet
How is the NanoStation M2 powered?
It uses passive Power over Ethernet (PoE) on pairs 4,5+ and 7,8 return.
From: Ubiquiti NanoStation M2 2.4GHz Hi‑Power 2x2 MIMO AirMax TDMA Station Datasheet
