Featured Traco manuals

Traco DC/DC Converters and AC/DC Power Supplies Product Leaflet

Product Leaflet 8 pages · 470 KB · EN

This leaflet showcases Traco's extensive portfolio of DC/DC converters and AC/DC power supplies for industrial applications. It lists numerous series such as TMR‑2, TMA, TMV, TMH, TEN‑15, TSP, TBL and TXL, providing key performance data, efficiency, input voltage ranges, output options and environmental ratings.

The document also highlights compliance with safety and EMC standards (IEC/EN/UL 60950‑1, EN 55022, ATEX, etc.) and notes that all SMD products are qualified for lead‑free reflow soldering. Technical details for each series include power ratings from 1 W up to 150 W, wide input voltage ranges, isolation voltages and operating temperature limits.

Covers: DC/DC Converters · AC/DC Power Supplies · Series TMR‑2 / TMR‑3 · Series TMA / TME / TMV / TMH · Series TEN‑15 / TEN‑30 / TEN‑40 · Series TMP / TMT / TMLM

Latest Traco manuals

• TRACO TMS Series 6 10 15 25 Watt handbook(1)

  The TMS series switching power supplies offer high power density in a low profile package, making them suitable for space-critical applications. They feature easy installation with flexible connection systems (solder pins, terminal block, FASTON-tabs). The product complies with international EMC specifications and safety standards and is suitable for worldwide use. The power modules are constructed using SMD technology and industrial grade components, ensuring high reliability.

• TRACO TMS Series 6 10 15 25 Watt handbook

  TMS series are ultraminiature AC/DC switching power supply modules from Traco Power. The module features high power density and low profile package, making it the best choice for space critical applications. TMS series is available in 3 package styles: PCB mounting with solder pins, chassis mounting with FASTON-Tabs and chassis mounting with screw terminals.

• TRACO POWER TMLM Series Encapsulated Power Supply

  TMLM series 10 watt encapsulated power supplies, offer highest power density in a fully encapsulated module. This feature makes these modules an ideal solution for all space critical applications in commercial and industrial elec- tronic equipment. Full compliance to European low voltage and EMC directive, UL and cUL safety approval qualifies this product for worldwide markets.

• TRACO POWER TML Series Encapsulated Power Supply

• TRACO POWER THD 10 Series 10 Watt Data Sheet

  The THD-10 series is a range of isolated high performance 10W DC/DC converters in a low profile DIL-24 package with standard industry pin-out. Other features of this product are built-in overvoltage protection and internal EMI filter to meet EN 55022, class A. Full SMD-design with exclusive use of ceramic capacitors guarantees high reliability and long product lifetime. Typical applications for these converters are industrial electronics, instrumentation, data communication systems, and battery operated equipment with limited space available on the PCB.

• TRACO POWER MHV Series handbook

  This document describes the features and characteristics of Traco Power's MHV series high voltage power modules, including the world's most compact design, SMD and hybrid technology, positive or negative polarity models, PCB and flying lead versions, excellent output stability, low temperature coefficient, ultra low ripple, remote voltage programming, short circuit protection, and shielded metal case.

• TRACO POWER TMV Series 1 Watt DC/DC Converter

  The TMV series is a miniature, isolated 1 W DC/DC converter with high isolation in a Single-in-Line package (SIP). Requiring only 1.2 cm2 board space, they offer the ideal solution in many space critical applications for board level power distribution. The use of SMD- technology makes it possible to offer a product with high performance at low cost.

• TRACO POWER TEM 3 Series 3 Watt DC/DC Converter

  The TEM 3 series is a range of isolated dc/dc converters in a DIL-24 package. They offer tight output regulation and very low output noise. Operating temperature range is –25 °C to +70°C. This product series provides a cost effective solution for many industrial or consumer electronics applications.

• TRACO POWER DC/DC Converter handbook

• TRACO POWER DC/DC Converter TME Series 1 Watt

  TME series is a range of sub-miniature , isolated DC/DC-con- verters in a SIP-package, which requires only 0.7 cm2 of board space. They provide a cost effective solution to generate supplemen- tary, isolated voltages.

• TRACO POWER Switching Power Supplies ESP Series 18 - 150 Watt

  This range of very compact switching power supplies are designed for all applications, where high reliability and long lifetime are important. They provide excellent electric specifications and full compliance to the European EMC and Low Voltage Directive. Universal input and international safety approvals qualify these power supplies for worldwide use. With their low profile case and screw terminal block they are easy to install in any equipment.

• TRACO POWER TEN 12 Series 12 Watt Data Sheet

  The TEN 12 series of DC/DC converters has been designed for a wide range of applications including communications, industrial systems and battery pow- ered mobile equipments. Key features are high power density (12W in a 2“x1“x 0.4“ package) and ultrawide input ranges of 9– 36 VDC and 18 – 75 VDC. Other features of this converter are internal filtering according to EN 55022, level A, safety approval to EN 60950 and UL 1950, wide oper- ating temperature range and remote on/off (opt.).

• TRACO POWER TEP 75WI Series 75 Watt DC/DC Converters handbook

  The TEP-75WI Series is a family of isolated high performance dc-dc converter modules with ultra-wide 4:1 input voltage ranges which come in a rugged, sealed metal case.

• TRACO POWER TPM Series Mini Switcher Manual

  The TPM Series 5, 10, 15, 30 Watt are miniature AC/DC switching power modules produced by Traco Power. These modules are available in PCB mounting and chassis mounting options, and can provide single, dual, or triple outputs. The input range is 85-264 VAC, 47–400 Hz, and the rated power is 5, 10, 15, and 30 watts. The TPM Series switching power modules comply with the European low voltage and EMC directive and have been UL and cUL certified.

• TRACO DC/DC-Converter TEG Series 3 Watt handbook

  TEG series 3 watt DC/DC converters feature wide input voltage ranges, regulated outputs, high efficiency, and high reliability. They are suitable for applications with limited space requirements, such as in telecom.
