Key facts
- Manuals
- 4
- Languages
- EN
- Last added
- 2026-10-01
Featured Scantech manuals
Scantech AM-CELL C200 Optical Automated 3D Measurement System Product Data Sheet
The AM‑CELL C200 provides a modular, plug‑and‑play solution for measuring medium‑sized parts on shop floors, CMM rooms, and in educational settings. Its active safety system with ten‑grade collision detection allows operators to work directly alongside the robot without a physical fence.
Technical specifications include a 2.5 kW control system, 200 kg payload, maximum object size of Ø1500 mm, and measurement accuracy up to 0.025 mm. The system can capture up to 2.6 million measurements per second over a scanning area of 500 mm × 600 mm, using a Class II eye‑safe laser.
Covers: Product Overview · Modular Design and Flexible Layouts · Active Safety System · Intelligent 3D Optical Measurement · Technical Specification · Vast Applications
SCANTECH M-Track Intelligent Robotic Path Planning and Guiding System Product Leaflet
SCANTECH's M-Track is an intelligent wireless solution that combines a 3D tracking system, a tool simulator, and path‑planning software. It captures 6D poses of a tool simulator to generate safe, efficient robot paths for applications such as grinding, coating, and welding.
The system delivers tracking accuracy of 0.064 mm (10.4 m³) and 0.078 mm (18 m³), operates at a 60 Hz tracking frequency, and works in temperatures from –10 °C to 40 °C. It is compatible with ABB, KUKA, FANUC and EFFORT robot models and supports both indoor and outdoor environments.
Covers: Intelligent Wireless Solution · System Overview · Technical Specification · Workflow · Compatibility
ScanTech KSCAN-Magic Composite 3D Scanner Technical Proposal
The KSCAN‑Magic series is a handheld composite 3D scanner that combines infrared and blue laser technologies with five standard scanning modes, including ultra‑fast and deep‑hole scanning. It offers high accuracy, a large scanning area, and an optional built‑in photogrammetry system for complex surface measurement.
The document provides a company overview, product specifications, configuration options, customer support details, and example application cases across automotive, aerospace, power generation, and more.
Covers: Company Introduction · Product Overview · Operation Principles · Features · Technical Parameters · Applications
Scantech Nexus N-3030 Implement User Manual
The Nexus N-3030 is a barcode laser scanning implement produced by Scantech. It is designed for integration with POS systems and includes multiple communication ports.
The device offers RS232C, RS485, Keyboard Wedge and USB interfaces, operates at 5.2 V with a current draw of 0.64 A, and is rated for temperatures up to 40 °C. Compliance markings include FCC and EN55022. For assistance, Scantech provides contact details in the manual.
Covers: Introduction · Safety Information · Technical Specifications · Interface Connections · Compliance and Certifications · Contact Information
Latest Scantech manuals
Scantech AM-CELL C200 Optical Automated 3D Measurement System Product Data Sheet
Product Leaflet 4 pages · 521 KB · ENThe Scantech AM-CELL C200 is an all‑in‑one optical automated 3D measurement system offering modular design, active safety and high‑precision scanning up to…
SCANTECH M-Track Intelligent Robotic Path Planning and Guiding System Product Leaflet
Product Leaflet 3 pages · 224 KB · ENThe SCANTECH M-Track system provides 6D pose tracking and automatic path planning for robots, offering high accuracy and easy deployment across various…
ScanTech KSCAN-Magic Composite 3D Scanner Technical Proposal
Product Leaflet 11 pages · 826 KB · ENTechnical proposal for the ScanTech KSCAN‑Magic handheld 3D scanner, detailing features, specifications and applications.
Scantech Nexus N-3030 Implement User Manual
User Manual 42 pages · 602 KB · ENThe Scantech Nexus N-3030 implement user manual provides operating instructions, interface details and compliance information for the barcode laser scanner.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in Scantech manuals
What is the maximum object size the AM‑CELL C200 can measure?
It can measure objects up to a diameter of 1500 mm.
From: Scantech AM-CELL C200 Optical Automated 3D Measurement System Product Data Sheet
How much payload can the AM‑CELL C200 handle?
The system supports an object payload of 200 kg.
From: Scantech AM-CELL C200 Optical Automated 3D Measurement System Product Data Sheet
What tracking accuracy does the M-Track system achieve?
It reaches 0.064 mm accuracy within a 10.4 m³ range and 0.078 mm within an 18 m³ range.
From: SCANTECH M-Track Intelligent Robotic Path Planning and Guiding System Product Leaflet
Which robot brands are compatible with M-Track?
M-Track works with ABB, KUKA, FANUC and EFFORT robot models.
From: SCANTECH M-Track Intelligent Robotic Path Planning and Guiding System Product Leaflet
What is the measurement accuracy of the KSCAN‑Magic scanner?
The scanner provides an accuracy of 0.020 mm.
From: ScanTech KSCAN-Magic Composite 3D Scanner Technical Proposal
What interface does the scanner use for data transfer?
The device uses a USB 3.0 interface.
From: ScanTech KSCAN-Magic Composite 3D Scanner Technical Proposal
