ASTRODYNE Manuals

Key facts

Manuals

8

Languages

EN

Last added

2012-06-07

Featured ASTRODYNE manuals

Astrodyne ASM60 Series 60W Ultraminiature Medical Open Frame Switching Power Supply Datasheet

Datasheet 4 pages · 775 KB · EN

The ASM60 series offers 60 W output power in a compact 1U‑compatible open‑frame design for medical equipment. It accepts a universal 90‑264 VAC input and provides single or dual outputs ranging from 5 VDC to 48 VDC, with efficiencies up to 86 % and 4000 V isolation.

Mechanical dimensions are 50.8 mm × 101.6 mm × 31.6 mm, weighing about 198 g. Connectors are JST or Molex series, with optional Molex “A” versions for single‑output models. The unit meets IEC‑60601‑1‑2, EN‑60601‑1, and CSA‑C22.2 safety standards and operates from –20 °C to +50 °C (extended to –40 °C to +85 °C storage).

Covers: Input Specifications · Output Specifications · Physical Specifications · Mechanical Dimensions · Environmental Specifications · Safety and Compliance

Astrodyne ASL365 High Density PFC Switcher Datasheet

Datasheet 4 pages · 1.1 MB · EN

The ASL365 series is a 365 W high‑density PFC switcher housed in a compact 3 × 5 × 1.28 in. open‑frame package. It provides three independent constant‑voltage outputs, including a 12 V auxiliary for fan drive and a 5 V standby output that can be powered from an external AC source or UPS. The unit meets Energy Star 4.0 (80‑Plus) requirements and is RoHS‑WEEE compliant.

Key features include a wide input voltage range of 90‑264 VAC, 90 % typical efficiency, 3 kV isolation, and multiple protection mechanisms such as short‑circuit, over‑voltage, and over‑current protection with auto‑recovery. Mechanical details, connector layouts, and derating curves are provided for integration into various applications.

Covers: Input Specifications · Output Specifications · Mechanical Specification · Derate Curve · Protection Features · Environmental Specifications

Latest ASTRODYNE manuals

• ASTRODYNE PV15 series

  The PV15 series compact 15 watt enclosed switching power supplies from ASTRODYNE USA feature high efficiency, regulated outputs, and built-in EMI filters.

• ASTRODYNE PMMK150-D series

  The Pmmk150-D series is a 150 watt medical grade power supply with DIN rail mount and PFC. This unit has a size of 3.2”W x 5.5”L x 1.6”H, 150 watts output power, single/dual outputs, 90-264VAC input, 5VDC to 48VDC outputs, 4000VAC input to output isolation and active power factor correction.

• ASTRODYNE AS-25 series

  as-25 series 25w single output switching power supply is a switching power supply with a rated output power of 25w. It has a wide input voltage range of 85~264vac and a wide output voltage range of 12v/15v/24v. The efficiency is 72%/76%/77% at 115vac and 80% at 115vac. It has a low no-load power consumption of 0.6a/115vac and 0.35a/230vac. The product has a variety of safety certifications and is suitable for a wide range of applications.

• Astrodyne PMK150U SERIES DATA SHEET

• ASTRODYNE QP-200 SERIES DATA SHEET

  This product is a 200W quad output power supply with PFC function, rated voltage is 127-370VDC, rated current is 3.5A/115VAC, 2A/230VAC, working temperature is -10~+60℃, working humidity is 20~90%RH.

• Astrodyne PMK150E series DATA SHEET

  The Astrodyne PMK150E series is a 150 Watt Enclosed Switching Power Supply with PFC. It features universal 90-264VAC input, 5VDC to 48VDC outputs, 3000VAC Input to Output Isolation and Active Power Factor Correction.

• Astrodyne ASM60 Series 60W Ultraminiature Medical Open Frame Switching Power Supply Datasheet

  Datasheet 4 pages · 775 KB · EN

  The Astrodyne ASM60 series provides 60 W ultraminiature medical open‑frame switching power supplies with up to 86 % efficiency and 4000 V isolation.

• Astrodyne ASL365 High Density PFC Switcher Datasheet

  Datasheet 4 pages · 1.1 MB · EN

  The Astrodyne ASL365 is a 365 W high‑density PFC switcher with 12 V auxiliary and 5 V standby outputs, offering 90 % efficiency and extensive protection.

Which document do I need?

Questions answered in ASTRODYNE manuals
