Jilin Sino-microelectronics 3TT8Z/V/C/J/F/U/S/E/F1 TRIAC Datasheet

Datasheet 15 pages · 994 KB · ZH

The 3TT8Z/V/C/J/F/U/S/E/F1 is a glass‑passivated three‑quadrant TRIAC designed for full‑wave AC control applications with high dV/dt and dI/dt, especially suitable for inductive loads such as motor control circuits. It is offered in multiple packages including TO‑220, TO‑220C, TO‑220S (internally isolated), TO‑220HF, DPAK, IPAK, TO‑263, TO‑262F and TO‑220MF‑K1.

Key specifications include a peak repetitive off‑state voltage of ±600 V or ±800 V, an on‑state RMS current of 8 A, and a peak gate trigger current of 35 mA. The device complies with RoHS requirements and is supplied in both halogen‑packed and halogen‑free options. This manual is written in Chinese.

Covers: General Description · Main Characteristics · Absolute Maximum Ratings · Electrical Characteristics · Thermal Characteristics · Electrical Isolation

Jilin Sino-microelectronics JCS7N65B N-Channel MOSFET Datasheet

Datasheet 10 pages · 645 KB · ZH

The JCS7N65B is an N‑channel enhancement‑mode MOSFET designed for high‑frequency switching power supplies, electronic lamp ballasts and UPS applications. It offers a 650 V drain‑source rating, low gate charge (25 nC) and fast switching performance while meeting RoHS requirements.

This datasheet provides absolute maximum ratings, detailed electrical parameters such as on‑resistance, gate charge and capacitances, thermal characteristics, mechanical dimensions for TO‑220C and TO‑220MF packages, and ordering information. Designers can use the curves and tables to verify suitability for their circuits. This manual is written in Chinese.

Covers: Main Characteristics · Absolute Ratings · Electrical Characteristics · Switching Characteristics · Thermal Characteristics · Package Mechanical Data

Jilin Sino-microelectronics JCS7N65F N-Channel MOSFET Datasheet

Datasheet 8 pages · 492 KB · EN

The JCS7N65F is a high‑frequency, low‑gate‑charge N‑Channel MOSFET intended for switch‑mode power supplies, electronic lamp ballasts, and UPS applications. The document lists its main characteristics, absolute ratings, and detailed electrical parameters.

Key specifications include a 650 V drain‑source voltage, 7 A continuous drain current, 1.35 Ω typical on‑resistance, and a total gate charge of 54 nC. Mechanical information such as the TO‑220MF package and a typical weight of 2.20 g are also provided, along with ordering codes and contact details for Jilin Sino-microelectronics.

Covers: Main Characteristics · Absolute Ratings · Electrical Characteristics · Switching Characteristics · Thermal Characteristics · Package Mechanical Data

Jilin Sino-microelectronics 30F120C Fast Recover Diode Datasheet

Datasheet 5 pages · 428 KB · ZH

The 30F120C fast recovery diode from Jilin Sino-microelectronics is designed for snubber circuits, switch‑mode power supplies, UPS systems and high‑frequency switching applications. The document provides ordering codes, mechanical data and recommended usage notes.

Key electrical parameters include a low forward voltage drop of 2.8 V, a forward current rating of 30 A, and a reverse voltage rating of 1200 V. Thermal resistance is 1.3 °C/W and the device is supplied in a TO‑220C2L package. Absolute maximum ratings and characteristic curves are listed for design reference. This manual is written in Chinese.

Covers: Product Features · Order Information · Main Characteristics · Absolute Maximum Ratings · Electrical Characteristics · Thermal Characteristics

Latest Jilin Sino-microelectronics manuals

• Jilin Sino-microelectronics 3TT8Z/V/C/J/F/U/S/E/F1 TRIAC Datasheet

  Datasheet 15 pages · 994 KB · ZH

  Technical data sheet for the 3TT8Z/V/C/J/F/U/S/E/F1 glass‑passivated three‑quadrant TRIAC from Jilin Sino‑microelectronics.

• Jilin Sino-microelectronics JCS7N65B N-Channel MOSFET Datasheet

  Datasheet 10 pages · 645 KB · ZH

  Technical datasheet for the JCS7N65B N‑channel MOSFET by Jilin Sino‑microelectronics, detailing ratings, electrical characteristics and packaging.

• Jilin Sino-microelectronics JCS7N65F N-Channel MOSFET Datasheet

  Datasheet 8 pages · 492 KB · EN

  The JCS7N65F N‑Channel MOSFET datasheet provides electrical characteristics, absolute maximum ratings, and mechanical data for design use.

• Jilin Sino-microelectronics 30F120C Fast Recover Diode Datasheet

  Datasheet 5 pages · 428 KB · ZH

  Datasheet for the Jilin Sino-microelectronics 30F120C fast recovery diode, detailing specifications, ratings, package and application information.

• Jilin Sino-microelectronics HBR5200 Schottky Barrier Diode Data Sheet

  Datasheet 5 pages · 215 KB · ZH

  The HBR5200 Schottky barrier diode data sheet provides electrical, thermal, and mechanical specifications from Jilin Sino-microelectronics.
