ZHIYUAN Electronics models by category
Featured ZHIYUAN Electronics manuals
ZHIYUAN ZY_BLS-1W Isolated Non‑Regulated Single‑Output Power Module Datasheet
The ZY_BLS-1W series provides a compact, high‑efficiency isolated power module without regulation. It features a 1000 VDC isolation voltage, UL94‑V0 flame‑retardant packaging, and operates over a wide temperature range of –40 °C to +85 °C. The module can be directly soldered onto a PCB and requires no external heat sink.
Designed for use with switch‑mode power supplies or other regulated sources, the module is suitable for applications such as high‑power IGBT drivers, digital circuits, low‑frequency analog circuits, and isolated communication interfaces (RS‑232, RS‑485, CAN‑bus). Electrical parameters, characteristic curves, and recommended circuit connections are detailed in the following sections. This manual is written in Chinese.
Covers: Pin Information · Electrical Parameters · Characteristic Curves · Product List · Circuit Connection · Declaration
Zhiyuan Electronics PCI-51XX CAN Interface Card User Manual
The PCI-51XX series is a PCI‑based CAN interface card that offers one or two electrically isolated CAN channels, supporting CAN 2.0A/B protocols and a baud‑rate range of 5 Kbps to 1 Mbps. Each channel includes full isolation, surge protection, and an optional 120 Ω termination resistor, making it suitable for reliable industrial communication networks.
The manual covers product features, hardware dimensions, electrical specifications, installation steps, driver installation for Windows, Linux and VxWorks, interface functions, test tools, troubleshooting FAQs, and sales/service contacts. It also provides detailed connector pin definitions and termination resistor configuration. This manual is written in Chinese.
Covers: Function Overview · Product Appearance · Device Parameters · Product List · Hardware Installation and Wiring · Connector Wiring
ZHIYUAN Electronics Technical Note Digital I/O Basics for Data Acquisition
This technical note from ZHIYUAN Electronics provides an overview of digital I/O fundamentals used in data acquisition, covering basic concepts, terminology and the role of digital signals in measurement systems.
It details input types (dry, wet, source, sink, differential), timing parameters such as rise/fall time and settling time, duty cycle, voltage level definitions, and sink/source output characteristics, along with a disclaimer on copyright. This manual is written in Chinese.
Covers: Overview · Digital I/O Concepts · Input Types · Rise and Fall Time · Settling Time · Duty Cycle
Zhiyuan Electronics EPC-8900 Embedded PC/104 Industrial Computer Board Data Sheet
The EPC-8900 is an embedded PC/104 industrial computer board developed by Zhiyuan Electronics. It features a XScale PXA270 processor, 2 MB boot ROM, 64 MB SDRAM, 256 MB NAND flash, and a rich set of I/O including dual isolated CAN, Ethernet, USB, RS‑232, and LCD interfaces. The board operates in a wide temperature range and can be supplied with a single 5 V source.
The document provides detailed hardware specifications, electrical parameters, mechanical dimensions, and supported software drivers for Windows CE 5.0 and MontaVista Realtime Linux. It also lists optional accessories and ordering information. This manual is written in Chinese.
Covers: 功能简介及相关参数 · 硬件参数 · 软件参数 · 电气参数 · 硬件接口 · 可选配件
Latest ZHIYUAN Electronics manuals
ZHIYUAN ZY_BLS-1W Isolated Non‑Regulated Single‑Output Power Module Datasheet
Datasheet 11 pages · 368 KB · ZHData sheet for the ZY_BLS-1W isolated non‑regulated single‑output power module with up to 80% efficiency and 1000 VDC isolation.
Zhiyuan Electronics PCI-51XX CAN Interface Card User Manual
User Manual 22 pages · 1.7 MB · ZHThe Zhiyuan Electronics PCI-51XX CAN interface card manual provides specifications, installation, driver setup, and usage details for the 1/2‑channel CAN card.
ZHIYUAN Electronics Technical Note Digital I/O Basics for Data Acquisition
Application Note 13 pages · 642 KB · ZHTechnical note explaining digital I/O concepts, input types, timing, voltage levels and sink/source output for data acquisition systems.
Zhiyuan Electronics EPC-8900 Embedded PC/104 Industrial Computer Board Data Sheet
Datasheet 36 pages · 5 MB · ZHData sheet for the EPC-8900 PC/104 embedded industrial computer board with dual isolated CAN interfaces.
Zhiyuan Electronics ZWG-13A GPRS Modem User Manual
User Manual 22 pages · 1.1 MB · ZHUser manual for the Zhiyuan Electronics ZWG-13A industrial‑grade external GPRS modem, covering installation, configuration, and phone/SMS functions.
ZhiYuan Electronics PC104-CAN2 CAN Interface Card User Manual
User Manual 28 pages · 2 MB · ZHThe ZhiYuan PC104-CAN2 dual CAN interface card manual provides specifications, installation, wiring, driver setup and maintenance details.
ZHIYUAN Electronics ZNE-100TL Ethernet to Serial Module User Manual
User Manual 80 pages · 2.5 MB · ZHThe ZHIYUAN Electronics ZNE-100TL Ethernet‑to‑Serial module manual provides setup, configuration, and operation instructions.
Which document do I need?
Datasheet
Ratings, dimensions and ordering codes, for selection and design work.
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Application Note
How to use the product for one specific task, with worked examples.
Questions answered in ZHIYUAN Electronics manuals
What is the isolation voltage of the ZY_BLS-1W module?
The module provides an isolation voltage of 1000 VDC.
From: ZHIYUAN ZY_BLS-1W Isolated Non‑Regulated Single‑Output Power Module Datasheet
What is the maximum efficiency of the ZY_BLS-1W power module?
The module can achieve up to 80% efficiency.
From: ZHIYUAN ZY_BLS-1W Isolated Non‑Regulated Single‑Output Power Module Datasheet
How many CAN channels does the PCI‑5110 provide?
The PCI‑5110 model provides a single CAN channel.
From: Zhiyuan Electronics PCI-51XX CAN Interface Card User Manual
What operating systems are supported by the PCI‑51XX card?
The card supports Windows 98/Me, Windows 2000, Windows XP, Linux, and VxWorks.
From: Zhiyuan Electronics PCI-51XX CAN Interface Card User Manual
What is a dry node in digital I/O?
A dry node is a passive switch with two interchangeable states and no polarity, used for signals like limit switches or push buttons.
From: ZHIYUAN Electronics Technical Note Digital I/O Basics for Data Acquisition
How is rise time defined?
Rise time is the time a signal takes to go from 20 % to 80 % of its high voltage level.
From: ZHIYUAN Electronics Technical Note Digital I/O Basics for Data Acquisition
