Bently Nevada Manuals

Key facts

Manuals

6

Models

2

Languages

EN

Last added

2026-10-03

Bently Nevada models by category

Featured Bently Nevada manuals

Bently Nevada 3500/42M Proximitor/Seismic Monitor Datasheet

Datasheet 18 pages · 399 KB · EN

The 3500/42M Proximitor/Seismic Monitor is a four‑channel condition‑monitoring module that accepts proximity and seismic transducer inputs. It provides vibration, position and other static measurements, with programmable alarm setpoints for machinery protection and operational insight.

The document lists detailed electrical characteristics, environmental limits, physical dimensions, and ordering options for I/O modules, barrier modules, cables and accessories. It also includes frequency‑response data, alarm configuration guidelines, and certification information for various safety agencies.

Covers: Specifications and Ordering Information · Inputs · Outputs · Signal Conditioning · Frequency Response · Alarms

Bently Nevada 330500 Velomitor Piezo-velocity Sensor Datasheet

Datasheet 14 pages · 854 KB · EN

The Bently Nevada 330500 Velomitor Piezo‑velocity Sensor is a solid‑state piezoelectric accelerometer designed for absolute vibration measurement on bearing housings, casings, or structural components. It features integrated electronics, no moving parts, and can be mounted in any orientation.

The datasheet provides detailed specifications, environmental limits, hazardous‑area approvals, ordering options, and accessory part numbers. It also includes dimensional drawings, typical response curves, and compliance information for FCC, EMC, RoHS, and various ATEX/IECEx standards.

Covers: Description · Specifications · Physical Characteristics · Compliance and Certifications · Hazardous Area Approvals · ATEX/IECEx

Bently Nevada 2300/20 and 2300/25 Vibration Monitors Datasheet

Datasheet 25 pages · 1.6 MB · EN

The 2300 series vibration monitors are designed for continuous condition monitoring and protection of less‑critical machinery across industries such as oil & gas, power generation, water treatment, and mining. They accept two acceleration/velocity/proximity inputs, a dedicated speed channel, and provide real‑time measurements with alarm configuration.

Key features include Ethernet 10/100 Base‑T communication, configurable 4‑20 mA outputs (2300/20) or Trendmaster SPA interface (2300/25), three buffered transducer outputs, and extensive compliance certifications (FCC, ATEX, IECEx, RoHS). The monitors are panel‑mountable, support Modbus over Ethernet, and can store alarm data during network outages.

Covers: Description · Key Features · Specifications · Communications · Compliance and Certifications · Ordering Information

Bently Nevada Velomitor and Pepperl+Fuchs KFD2-VR4-EX1.26 Application Note

Application Note 3 pages · 5.5 MB · EN

The note describes the hardware setup required to interface the Velomitor with the KFD2‑VR4‑EX1.26 isolator, including jumper settings, external power supply connection, and wiring polarity. It also warns that the 3500/42M monitor cannot supply enough current for the isolator, so a +24 VDC external supply must be used.

Software configuration steps are provided for the Rack Configuration software, covering channel pair selection, transducer type settings, and OK‑limit adjustments. The document lists conditions that trigger a NOT OK state on the monitor and points to additional resources on both manufacturers' websites.

Covers: Introduction · Hardware Setup · Software Configuration · Wiring Diagram · NOT OK Checking · Summary

Latest Bently Nevada manuals

• Bently Nevada 3500/42M Proximitor/Seismic Monitor Datasheet

  Datasheet 18 pages · 399 KB · EN

  Technical specifications and ordering information for the Bently Nevada 3500/42M Proximitor/Seismic Monitor.

• Bently Nevada 330500 Velomitor Piezo-velocity Sensor Datasheet

  Datasheet 14 pages · 854 KB · EN

  The 330500 Velomitor Piezo‑velocity Sensor is a solid‑state accelerometer with a 4.5 Hz‑5 kHz range, 12 kHz resonant frequency, and up to 1 000 ft cable length.

• Bently Nevada 2300/20 and 2300/25 Vibration Monitors Datasheet

  Datasheet 25 pages · 1.6 MB · EN

  The Bently Nevada 2300/20 and 2300/25 vibration monitors provide continuous monitoring, 4‑20 mA or SPA outputs, Ethernet connectivity, and advanced…

• Bently Nevada Velomitor and Pepperl+Fuchs KFD2-VR4-EX1.26 Application Note

  Application Note 3 pages · 5.5 MB · EN

  This application note explains how to connect a two‑wire Bently Nevada Velomitor to a Pepperl+Fuchs KFD2‑VR4‑EX1.26 voltage repeater for use with a 3500/42M…

• Bently Nevada 330400 and 330425 Accelerometer Acceleration Transducers Datasheet

  Datasheet 11 pages · 983 KB · EN

  The Bently Nevada 330400 and 330425 accelerometer datasheet provides specifications, environmental limits, compliance certifications, and ordering information.

• Bently Nevada ADAPT 3701/44 Aero Monitor Product Datasheet

  Datasheet 26 pages · 1 MB · EN

  The ADAPT 3701/44 Aero Monitor is a compact, high‑performance safety and condition‑monitoring device for aeroderivative gas turbines.

Which document do I need?

Questions answered in Bently Nevada manuals
