Key facts
- Brand
- SMC
- Model
- TigerSwitch 10
- Category
- Network Switches
- Industry
- Electronics
- Documents
- 4
- Languages
- EN
- Last added
- 2012-03-20
Start here
SMC TigerSwitch 10/100/1000 User Manual
This manual introduces the TigerSwitch 10/100/1000 Gigabit Ethernet switch, describing its key features such as 12 SFP ports, 4 RJ45 ports, non‑blocking architecture, and support for redundant power. It also outlines the warranty and safety information provided by SMC Networks.
The guide details initial configuration steps, console and web interface usage, IP address setup, VLAN and QoS configuration, SNMP management, DHCP/BOOTP, firmware updates, logging, and security features like 802.1x and ACLs. Contact information for technical support worldwide is included at the end.
SMC TigerSwitch 10 specifications
| SFP ports | 12 1000BASE‑X |
|---|---|
| RJ45 ports | 4 (shared with 4 SFP slots) |
| Jumbo frame size | up to 9 KB |
| LACP trunks | up to six 4‑port trunks |
| CoS queues | four priority queues (Layer 2/3/4) |
All SMC TigerSwitch 10 documents by type
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in these manuals
How many SFP ports does the TigerSwitch have?
The TigerSwitch provides twelve 1000BASE‑X SFP ports.
What is the maximum jumbo frame size supported by the switch?
It supports jumbo frames up to nine kilobytes.
How many SFP ports does the TigerSwitch have?
The TigerSwitch provides twelve 1000BASE‑X SFP ports.
What management interfaces are supported by the TigerSwitch?
The switch can be managed via a console connection, a web interface, and SNMP/RMON.
What management methods are supported by the switch?
The switch can be managed via a console connection, a web interface, SNMP, and RMON.
What is the maximum aggregate bandwidth of the device?
The aggregate bandwidth is 8.8 Gbps for the 24‑port version and 17.6 Gbps for the 48‑port version.
