Key facts
- Brand
- Siteco
- Model
- SiCompact S2 MAXI
- Category
- LED Power
- Industry
- Industrial
- Documents
- 2
- Languages
- EN · ZH
- Last added
- 2012-01-16
Start here
Sitecо SiCompact S2 MAXI Product Leaflet
Product Leaflet 1 pages · 57 KB · EN
The SiCompact S2 MAXI is a high‑power LED luminaire designed for industrial and commercial lighting. It delivers 1,000 W of power with a luminous flux of 95,000 lm and a colour temperature of 5,900 K, while maintaining a colour rendering index of ≥90.
The fixture features a die‑cast aluminium housing, IP65 protection, and a weight of 20.5 kg. It includes safety features such as a protective glass cover, tool‑free lamp replacement, and a pressure‑equalisation system to prevent condensation.
Siteco SiCompact S2 MAXI specifications
| Wattage | 1,000W |
|---|---|
| Luminous Flux | 95,000 lm |
| Luminous Efficiency | 95 lm/W |
| Colour Temperature | 5,900K |
| Colour Rendering Index | ≥90 |
| Voltage | 220‑230V / 50 Hz |
| Current | 9.6 A |
| Efficiency | 69.5 % |
| Housing Material | Die‑cast aluminium |
| Weight | 20.5 kg |
| IP Rating | IP65 |
All Siteco SiCompact S2 MAXI documents by type
Product Leaflet 1
Datasheet 1
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in these manuals
What is the wattage of the SiCompact S2 MAXI?
The SiCompact S2 MAXI operates at 1,000 W.
What is the IP protection rating?
The fixture is rated IP65.
What is the power rating of the SiCompact S2 MAXI lamp?
It is rated at 2,000 W.
What luminous output does the lamp provide?
The lamp produces 200,000 lm of light.
