Featured WELLSON manuals
Wellson WSRD200 Intelligent Radar Level Meter Installation Manual
This manual describes the WSRD200 series intelligent radar level meter, which can be used for liquid, solid, and slurry level measurement in tanks and pipelines. It explains the microwave measurement principle, signal processing, and how the device converts reflected signals into accurate level readings.
The document includes detailed installation instructions, internal mounting guidelines, measurement conditions, safety precautions, and technical specifications such as measurement range, temperature and pressure limits, accuracy, and signal output options. It also covers explosion‑proof (IP68) configurations and wiring requirements for 4‑20 mA HART communication. This manual is written in Chinese.
Covers: Introduction · Installation Guide · Internal Installation · Measurement Conditions · Precautions · Technical Specifications
WELLSON WSF-100 Ultrasonic Flow Meter User Manual
This manual covers the WSF-100 series ultrasonic flow meter and heat meter, describing its purpose, key features, and safety precautions. It explains the time‑difference measurement principle and the device's suitability for continuous measurement of clean, uniform liquids in industrial settings.
The document is organized into sections on quick installation, sensor wiring, grounding, power supply options, parameter setup, operation, technical data, error codes, extended protocol, and a FAQ. Detailed guidance is given for sensor placement, coupling agent use, signal quality checks, and troubleshooting common issues such as signal loss or incorrect current‑loop output. This manual is written in Chinese.
Covers: Overview · Quick Installation Guide · Installation and Measurement · Working Principle · Technical Data · Selection Codes
Latest WELLSON manuals
Wellson WSRD200 Intelligent Radar Level Meter Installation Manual
User Manual 13 pages · 339 KB · ZHThe Wellson WSRD200 manual provides installation, operation, and measurement guidelines for the intelligent radar level meter.
WELLSON WSF-100 Ultrasonic Flow Meter User Manual
User Manual 54 pages · 644 KB · ZHThe WELLSON WSF-100 ultrasonic flow meter user manual provides installation, operation, maintenance, and troubleshooting instructions.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in WELLSON manuals
What is the minimum installation distance from the tank wall?
The sensor must be installed at least 200 mm away from the outer wall of the tank.
From: Wellson WSRD200 Intelligent Radar Level Meter Installation Manual
What signal output does the WSRD200 provide?
It provides a 4–20 mA HART output signal.
From: Wellson WSRD200 Intelligent Radar Level Meter Installation Manual
Why is there no output current from the current loop?
Check the M55 window to ensure the required current‑output mode is selected and not set to “closed current loop”.
Why does the meter show zero instantaneous flow even though fluid is present?
If a static zero point was set while fluid was flowing, clear it using the M42/M43 settings to restore the original zero point.
