SMSC models by category
Featured SMSC manuals
SMSC LAN83C183 Fast Ethernet PHY Datasheet
The SMSC LAN83C183 is a highly integrated Fast Ethernet PHY supporting 10/100 Mbps operation, dual‑speed, half‑ and full‑duplex, and auto‑negotiation. It features a 64‑pin TQFP package, 3.3 V supply with 5 V‑tolerant I/O, and MII interface to an Ethernet controller.
The document provides functional description, signal definitions, register maps, management interface details, electrical specifications, pinout and mechanical drawings, and ordering information for the device.
Covers: Features · Ordering Information · Functional Description · Signal Descriptions · Registers · Management Interface
SMSC EMC6D103S-CZC-TR Manual
The EMC6D103S is an environmental monitoring and fan‑control IC that supports high‑frequency PWM outputs, hardware monitoring of up to five voltages and three thermal zones, and SMBus 2.0 communication. It is offered in a 24‑pin SSOP, lead‑free, RoHS‑compliant package.
Key features include 3 PWM fan‑speed outputs, 4 fan tachometer inputs, programmable automatic fan control based on temperature zones, two low‑power modes (Sleep and Shutdown), and a range of limit‑comparison registers for voltage and temperature protection.
Covers: General Description · Pinout · Pin Description · Operational Description · SMBus Interface · Hardware Monitoring
SMSC TMC2072 Datasheet
The TMC2072 is a low‑power CMOS networking controller that operates from a 3.3 V supply with 5 V‑tolerant I/O. It supports both 8‑bit and 16‑bit data buses, includes a 1 KB dual‑port buffer memory, and can connect up to 31 nodes in a CircLink network with packet sizes up to 256 bytes. The device is offered in a 100‑pin TQFP, lead‑free RoHS‑compliant package and works over a temperature range of 0 °C to 70 °C.
The datasheet contains a general description, functional description, detailed register map, pin configuration tables, and appendices covering the CMI modem, crystal oscillator circuit, package outline, marking specifications, and electrical characteristics. Ordering information, package parameters, and comparative tables with related parts are also provided.
Covers: General Description · Functional Description · Register Descriptions · Pin Configuration · Electrical Characteristics · Package Outline
SMSC USB3500 USB 2.0 PHY Datasheet
The SMSC USB3500 is a stand‑alone Hi‑Speed USB PHY that supports High‑Speed, Full‑Speed, and Low‑Speed data rates as a host, device, or OTG PHY. It complies with USB‑IF Hi‑Speed certification, the UTMI+ specification, and includes full support for the optional On‑The‑Go (OTG) protocol.
The device is offered in a compact 56‑lead QFN package (8 × 8 × 0.9 mm) and is targeted for applications such as cell phones, MP3 players, scanners, printers, external hard drives, cameras, and other portable media devices. Electrical characteristics include low power consumption (55 mA unconfigured, 83 µA suspend) and operation over a commercial temperature range of 0 °C to +70 °C.
Covers: General Description · Functional Overview · Pin Configuration and Pin Definitions · Limiting Values · Electrical Characteristics · Detailed Functional Description
Latest SMSC manuals
smsc USB97CFDC USB Floppy Disk Controller Manual
SMSC DS – USB97CFDC Rev. 12/15/2000 USB97CFDC USB Floppy Disk Controller is a USB floppy disk controller produced by SMSC. It supports 640K, 720K, 1.44M, 1.2M Windows 98 J, and 1.2M NEC DOS 6.x formats.
smsc USB97C202 USB 2.0 ATA/ ATAPI Controller handbook
USB97C202 is a USB 2.0 ATA/ ATAPI controller from SMSC. The controller supports 2.5 volt low power core operation, 3.3 volt I/O, and is compatible with USB 2.0 specifications. It also supports USB Mass Storage Compliant Bootable BIOS.
smsc USB97C201 Rev 1.5 USB 2.0 ATA/ ATAPI Controller handbook
The USB97C201 is a USB 2.0 ATA/ATAPI controller from SMSC. It supports USB 2.0 specifications and supports USB Mass Storage Compliant Bootable BIOS.
smsc USB97C100 ADVANCE INFORMATION Multi-Endpoint USB Peripheral Controller handbook
SMSC DS - USB97C100 is a multi-endpoint USB peripheral controller with high performance, complete USB 1.1 compatibility, high-speed capability, dynamic hardware allocation, and extended power management.
SMSC USB3450 Manual
USB3450 is a USB PHY chip from SMSC that supports USB 2.0 Hi-Speed and USB 1.1. It supports 480Mbps data rate, has a low latency receiver, internal 1.8V regulators, short circuit protection, 24MHz crystal oscillator, PLL and 40-pin QFN package.
SMSC USB3300 Manual
The SMSC USB3300 is a high-performance USB host or device PHY with ULPI Low Pin Interface. It meets USB-IF“Hi-Speed” certification and the Universal Serial Bus Specification Rev 2.0 requirements, and is compliant with the ULPI Specification revision 1.1 in 8-bit mode.
SMSC GT3200/USB3250 Manual
This document describes the features and characteristics of SMSC GT3200 and SMSC USB3250, including USB-IF certification, support for USB2.0 specification, support for data transmission rates of 480Mbps and 12Mbps, integrated termination resistors, internal short circuit protection, low power consumption, etc.
smsc USB2601/USB2602 4th Generation USB2.0 Flash Media Controller with Integrated Card Power FETs HS Hub handbook
USB2601/USB2602 is a 4th generation USB2.0 flash media controller with integrated card power FETs and HS Hub Hub controller.
smsc USB2231/USB2232 5th Generation Hi-Speed USB Flash Media CIR Controller with Integrated Card Power FETs handbook
USB2231/USB2232 is the 5th generation Hi-Speed USB Flash Media and CIR controller with integrated card power FETs from SMSC, supporting all popular CIR formats.
smsc USB2224 Bus Powered USB2.0 Flash Media Controller handbook
SMSC USB2224 is a USB2.0 flash media controller that supports SmartMedia™, xD Picture Card™, Memory Stick™, High Speed Memory Stick™, Memory Stick PRO™, MS Duo™, Secure Digital™, Mini-Secure Digital™, Transflash™, MultiMediaCard™, Reduced Size Multimedia Card™, NAND Flash, Compact Flash™, CF Ultra™ I & II, CF form-factor ATA hard drives.
smsc USB2223-03 Bus Powered USB2.0 Flash Media Controller handbook
SMSC USB2223-03-03 is a USB2.0 flash media controller that provides a complete system solution for interfacing various storage devices to the USB2.0 bus. It supports SmartMediaTM (SM), Memory StickTM (MS), High Speed Memory Stick (HSMS), Memory Stick PROTM (MSPRO), Memory Stick DuoTM (MSDUO), Secure Digital (SD), Mini-Secure Digital (Mini-SD), Transflash (SD), MultiMediaCardTM (MMC), Reduced Size Multimedia Card (RS-MMC), NAND Flash, Compact FlashTM (CF), CF UltraTM I&II, and CF form-factor ATA hard drives. It allows simultaneous operation of the supported devices, but only one device from each group (CF or ATA drive, SM or NAND, SD or MMC) can be operated at a time. The controller includes on-chip 4-bit high speed Memory Stick and MS PRO hardware circuitry, as well as 1-bit ECC correction for maximum efficiency. It is USB Bus Power Certified, has 3.3 Volt I/O with 5V input tolerance, and is fully compatible with USB Specification 2.0.
smsc USB20H04 handbook
This datasheet introduces the features of the SMSC USB20H04 4-Port USB2.0 Hub Controller, which is compliant with the USB2.0 specification, supports four downstream ports, and has four transaction translators to ensure maximum USB throughput. The controller supports bus-powered Hi-Speed hub design and is compatible with On-The-Go (OTG) USB devices.
SMSC USB2005 Manual
SMSC USB2005 is a USB2.0 ATA/ATAPI controller with PD-DRM function, which can provide digital rights management for portable devices (PD-DRM) via Mass Storage Class SCSI Inquiry command as specified by Microsoft for Windows Media Systems (WM-DRM). Reports all media as Removable (HDDs only).
smsc Application Note 10.8 USB97C223 USB97C243 Capacitor Selection for Internal Regulator Output Pins
This application note describes the capacitor selection for the internal regulator output pins of the USB97C223 and USB97C243
SMSC LPC47M14x PRELIMINARY handbook
This is a technical manual for SMSC LPC47M14X Super I/O controller
- 1
- 2
Which document do I need?
Datasheet
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in SMSC manuals
What supply voltage does the LAN83C183 require?
The device operates from a single 3.3 V supply and its I/O pins are 5 V‑tolerant.
How many pins does the LAN83C183 have?
It is offered in a 64‑pin TQFP package.
What monitoring modes does the EMC6D103S support?
It supports two monitoring modes: Continuous Mode and Cycle Mode.
How many thermal zones can be monitored?
The device can monitor three thermal zones – two external zones and one internal zone.
What is the maximum number of nodes supported by the TMC2072?
The TMC2072 can support up to 31 nodes in a CircLink network.
From: SMSC TMC2072 Datasheet
What temperature range can the TMC2072 operate in?
It operates from 0 °C up to 70 °C.
From: SMSC TMC2072 Datasheet
