Preliminary Manuals

Key facts

Manuals

5

Languages

ZH

Last added

2012-07-04

Featured Preliminary manuals

Princeton Technology PT5622 Switch Dimming Chip Datasheet

Datasheet 13 pages · 1.1 MB · ZH

The PT5622 is a dedicated control chip for electronic ballast dimming applications. It uses lamp‑current negative‑feedback closed‑loop control, offers programmable pre‑heat time and frequency, and supports three‑ or two‑step dimming modes. The chip integrates an MCU and provides both DIP16 and SOP16 package options.

The document includes a functional block diagram, pin descriptions, working logic tables for various dimming configurations, electrical characteristic limits, mechanical dimensions for both DIP and SOP packages, and ordering information. An important notice from Princeton Technology Corporation outlines product revision rights and liability. This manual is written in Chinese.

Covers: Description · Features · Pin Description · Working Logic · Dimming Modes · Electrical Characteristics

Latest Preliminary manuals

• PRELIMINARY USERS MANUAL

  The document involves the features and characteristics of the product, but the specific content cannot be parsed.

• PRELIMINARY Single Output UHP Models 3.3 Volts 30 Amps 100 Watt DC/DC Converters

  DATEL 3.3 Volts @ 30 Amps 100 Watt, DC/DC Converters Single Output UHP Models is a DATEL DC/DC converter for low-voltage/high-current applications. This converter uses a full-bridge, fixed-frequency topology with synchronous output rectification to achieve an efficiency of 89%. Additionally, the converter uses an open-frame package that allows unrestricted air flow, reducing internal component temperatures, allowing operation at elevated ambient temperatures. This DC/DC provides output trim, sense pins and primary side on/off control (available with positive or negative logic) or sync. Standard features also include input overvoltage and undervoltage shutdown circuitry, output overvoltage protection, output short-circuit and current limiting protection and thermal shutdown. All devices meet IEC950, UL1950 and EN60950 safety standards and carry CE certification.

• Preliminary BTA12-600B Semiconductor Manual

  BTA12-600B is a fully isolated package bidirectional triode thyristor suitable for AC switching application, phase control application.

• Princeton Technology PT5622 Switch Dimming Chip Datasheet

  Datasheet 13 pages · 1.1 MB · ZH

  Technical datasheet for the PT5622 switch‑dimming chip, detailing features, pinout, electrical specs and packaging.

• Preliminary TM57ML40 8 Position micro controller Manual

Which document do I need?

Questions answered in Preliminary manuals
