LIGHTSPACE models by category
Featured LIGHTSPACE manuals
Lightspace LT-6006DL Digital Light Dimmer User Manual
The Lightspace LT-6006DL is a six‑channel digital light dimmer that supports DMX512 input and provides up to 6 kW per channel (36 kW total). It features LCD display, lamp‑preheat, overload and short‑circuit protection, intelligent fan control and over‑temperature alarm, and complies with EN60950‑1 and EN60204‑1 safety standards.
The manual covers transport and storage conditions, safety precautions, cable connection, front‑ and rear‑panel descriptions, installation requirements, parameter settings, and troubleshooting methods. All installation, adjustment and maintenance work must be performed by qualified personnel with power disconnected. This manual is written in Chinese.
Covers: Transport and Storage Conditions · Safety Knowledge · Cable Connection Guidelines · Product Description · Technical Parameters · Installation Requirements
Lightspace LT-6006DL Digital Light Modulator User Manual
The Lightspace LT-6006DL is a 6‑channel digital light dimmer designed for professional lighting installations. It supports DMX512 control, offers up to 36 kW total output and includes built‑in protection features such as MCB overload and short‑circuit protection.
This user manual covers transport and storage conditions, safety guidelines, cable connection, front and rear panel descriptions, installation steps, parameter settings, and detailed troubleshooting procedures to ensure reliable and safe operation. This manual is written in Chinese.
Covers: Transportation and Storage Conditions · Delivery and Unpacking · Safety Knowledge · Cable Operation Precautions · Product Description · Technical Parameters
Lightspace LT-3005D Digital Light Dimmer User Manual
The LT-3005D is a six‑channel digital light dimmer designed for professional lighting applications. It supports the DMX512 protocol, offers 256 dimming levels per channel, and includes built‑in protection such as MCB overload and short‑circuit protection, intelligent fan control, and over‑temperature alarm.
The manual covers transport and storage conditions, safety precautions, power‑cable and signal‑cable connections, front‑ and rear‑panel descriptions, detailed installation steps, parameter settings via the LCD menu, and a range of detection, protection, and recovery methods for troubleshooting. This manual is written in Chinese.
Covers: Transport and Storage Conditions · Safety Knowledge · Cable Connection Guidelines · Product Description · Technical Parameters · Installation Requirements
Lightspace LT-1210K Intelligent Switch Controller User Manual
The LT-1210K is a professional intelligent switch controller designed for distributed lighting control systems. It offers 12 switch outputs, dual input interfaces (DMX‑512 and LT‑NET), and built‑in protection features.
This manual covers unpacking, safety guidelines, installation requirements, power and signal wiring, configuration of DIP switches, communication protocols, and troubleshooting methods such as emergency bypass and fault detection. This manual is written in Chinese.
Covers: Unpacking · Safety Information · Cable Handling · Main Functions · Product Features · Installation Requirements
Latest LIGHTSPACE manuals
Lightspace LT-6006DL Digital Light Dimmer User Manual
User Manual 16 pages · 226 KB · ZHUser manual for the Lightspace LT-6006DL six‑channel digital dimmer with DMX512 control and safety guidelines.
Lightspace LT-6006DL Digital Light Modulator User Manual
User Manual 16 pages · 226 KB · ZHThe manual provides safety, installation, wiring, operation and troubleshooting information for the Lightspace LT-6006DL 6‑channel digital light dimmer.
Lightspace LT-3005D Digital Light Dimmer User Manual
User Manual 16 pages · 226 KB · ZHThe Lightspace LT-3005D digital light dimmer user manual provides safety, installation, wiring, configuration, and troubleshooting instructions for the…
Lightspace LT-1210K Intelligent Switch Controller User Manual
User Manual 18 pages · 930 KB · ZHThe Lightspace LT-1210K Intelligent Switch Controller User Manual provides installation, wiring, safety, and operation instructions for professional use.
LIGHTSPACE LT-0410K intelligence Switch controller user manual
LIGHTSPACE LT-3005D digital Light modulator user manual
Lightspace LT-1203DA Digital Light Modulator User Manual
User Manual 16 pages · 349 KB · ZHThe Lightspace LT-1203DA digital dimmer manual provides safety, installation, wiring, and operation instructions for the 12‑channel, 3 kW per channel device.
LIGHTSPACE LT-1210K intelligence Switch controller user manual1
Lightspace LT-0610K Intelligence Switch Controller User Manual
User Manual 17 pages · 1016 KB · ZHThe Lightspace LT-0610K manual provides installation, wiring, safety and operation instructions for the intelligent switch controller.
LIGHTSPACE LT-1210KA User Manual
User Manual 18 pages · 1.2 MB · ZHThe LIGHTSPACE LT-1210KA user manual provides safety guidelines, installation instructions, wiring diagrams, and operation details for the intelligent…
Lightspace LT-0610K Smart Switch Controller User Manual
User Manual 18 pages · 998 KB · ZHUser manual for the Lightspace LT-0610K smart switch controller, covering safety, installation, wiring and operation.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in LIGHTSPACE manuals
What safety steps must be taken before servicing the dimmer?
Power must be disconnected and only qualified personnel should open the enclosure or perform repairs.
What type of protection does each channel have?
Each channel is protected by a micro‑circuit breaker (MCB) with a 6000 A breaking capacity, providing overload and short‑circuit protection.
How should the power cables be connected to the LT-6006DL?
Use a three‑phase 3NPE 400 V 50 Hz TN‑S system with L1, L2, L3 (brown or black), N (blue) and PE (yellow‑green) conductors, and follow the specified cable size requirements.
From: Lightspace LT-6006DL Digital Light Modulator User Manual
What is the allowable DMX address range for the dimmer?
The DMX start address can be set to any value between 1 and 512.
From: Lightspace LT-6006DL Digital Light Modulator User Manual
What safety steps must be taken before servicing the LT-1210K?
Power must be disconnected and only qualified personnel should open the enclosure or perform repairs.
From: Lightspace LT-1210K Intelligent Switch Controller User Manual
How many switch channels does the LT-1210K provide and what is their current rating?
The controller provides 12 switch channels, each rated for 10 A.
From: Lightspace LT-1210K Intelligent Switch Controller User Manual
