Featured IR manuals
IR Air Motor SM4AM Operation Maintenance Information Form P7621 Edition 3 Manual
This manual covers safe operation of the SM4AM air motor, including required personal protective equipment, emergency shut‑off valve placement, and the use of clean, dry air at the correct pressure. It also explains the meaning of safety symbols such as DANGER, WARNING, CAUTION and NOTICE.
Installation instructions recommend using a 1/2‑inch filter‑regulator‑lubricator (FRL) and provide line‑size guidelines. The motor’s vanes are made of a special material that does not require lubrication, though an FRL is suggested for optimal performance. Technical specifications such as power, speed, torque and air consumption are listed, and dimension drawings are provided for mounting.
Covers: General Product Safety Information · Using the Motor · Safety Symbol Identification · Model Identification · Installation · Lubrication
Ingersoll Rand SS815/SS825/SS850 Series Service Manual
This manual provides the safety information, intended use, and detailed procedures for installing and maintaining the SS815, SS825 and SS850 air starters, which are designed for starting reciprocating internal combustion engines. It includes guidance on proper lubrication, hose sizing, and pressure requirements.
Key sections cover product safety, starter orientation, mounting steps, lubrication system selection, and typical installation configurations for vehicular, stationary and engine‑prelube systems. The document also supplies torque specifications and recommended sealants for reliable operation.
Covers: Product Safety Information · Lubrication · Installation · Orientation of the Air Starter · Mounting the Air Starter · Typical Vehicular Installation
Latest IR manuals
IR IRL HEXFET Power MOSFET datasheet
This document provides specifications and features of the product IRL630PbF by IRF.
IR Air Motor SM4AM Operation Maintenance Information Form P7621 Edition 3 Manual
Service Manual 16 pages · 1.4 MB · ENThe Ingersoll Rand SM4AM Air Motor Operation and Maintenance Manual provides safety guidelines, installation steps, lubrication advice, specifications, and…
Ingersoll Rand SS815/SS825/SS850 Series Service Manual
Service Manual 36 pages · 2.8 MB · ENInstallation, orientation, lubrication and maintenance instructions for Ingersoll Rand SS815, SS825 and SS850 air starters.
Which document do I need?
Service Manual
Disassembly, diagnostics and part numbers, for repair.
Questions answered in IR manuals
What air pressure should be used with the SM4AM air motor?
Use clean, dry air at 90 psig (6.2 bar/620 kPa) as the maximum inlet pressure.
From: IR Air Motor SM4AM Operation Maintenance Information Form P7621 Edition 3 Manual
Does the SM4AM motor require lubrication?
The SM4AM series vanes are made of a special material that does not require lubrication, though an air‑line lubricator is recommended for optimum performance.
From: IR Air Motor SM4AM Operation Maintenance Information Form P7621 Edition 3 Manual
