Featured Asoni manuals
Asoni CAM438/CAM438W Network Camera User Manual
The CAM438 and CAM438W are compact network surveillance cameras featuring a 14‑inch CMOS sensor, 4 mm f/2.0 lens, and support for both wired Ethernet and optional 802.11b/g Wi‑Fi (CAM438W). They deliver video in MPEG‑4 or MJPEG formats up to 30 FPS at resolutions of 640×480, 320×240, and 160×120.
This manual covers hardware specifications, network configuration, video and audio settings, motion detection, alarm options, and installation requirements. It also lists compatible operating systems, browsers, and recommended PC hardware for viewing the camera streams. This manual is written in Chinese.
Covers: Technical Specifications · Network Connectivity · Video Settings · Audio Features · Power and Dimensions · Operating System Compatibility
Asoni CAM413 Network Camera User Manual
The Asoni CAM413 is a network surveillance camera featuring a 1/3" Sony SuperHad CCD sensor, a fixed 6 mm lens, and supports both MPEG‑4 and MJPEG video at up to 30 fps. It offers PoE power, optional Wi‑Fi, dual‑stream video, and built‑in microphone with an RCA audio output.
This manual provides installation instructions, power options (DC 12 V or IEEE 802.3af PoE), network configuration (10/100 Base‑T and 802.11b/g), digital alarm I/O, SD‑card storage, and detailed specifications of image resolution, dimensions, and supported protocols. This manual is written in Chinese.
Covers: Features Overview · Image Specifications · Audio and Alarm I/O · Power Supply Options · Network Connectivity · Physical Dimensions
Asoni CAM427M/CAM427M-PoE net camera Manual
The CAM427M is a network surveillance camera featuring a 1/4" CMOS sensor with up to 130万像素, a varifocal 10‑40 mm F1.4 lens, and infrared illumination up to 80 m. It supports both wired power (DC 12 V 2 A or AC 24 V) and PoE (IEEE 802.3at) and is rated IP‑66 for outdoor use.
The manual lists video formats (MPEG‑4, MJPEG), resolutions from 1280×1024 to 160×120, and frame rates up to 10 fps at full resolution. It also covers audio input/output, motion detection zones, alarm settings, and network protocols such as HTTP, RTP/RTSP, and UPnP.
Covers: Specifications · Power Options · Network Features · Video Settings · Audio Features · Installation
Latest Asoni manuals
Asoni Mega-Pixel Network Vandal Dome CAM419 User Manual
CAM419 Network Vandal Dome is a CMOS Network Vandal Dome. It builds in web server. User views real-time video via IE browser. CAM419 supports MPEG-4 & M-JPEG video compression which provides smooth and high quality video. The video can be stored in the SD card, and can be playback remotely.
Asoni CAM438/CAM438W Network Camera User Manual
User Manual 1 pages · 278 KB · ZHThe Asoni CAM438/CAM438W network camera user manual provides specifications, setup instructions, and feature details for the device.
Asoni CAM413 Network Camera User Manual
User Manual 1 pages · 314 KB · ZHThe Asoni CAM413 network camera user manual provides setup instructions, specifications, and features for PoE and Wi‑Fi models.
Asoni CAM427M/CAM427M-PoE net camera Manual
User Manual 1 pages · 291 KB · ENThe Asoni CAM427M net camera manual provides specifications, installation, and operation details for both wired and PoE versions.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in Asoni manuals
What are the power requirements for the CAM438 camera?
The camera requires a DC 12 V power supply with a current of 1 A.
Which video resolutions does the CAM438 support?
It supports 640×480, 320×240, and 160×120 pixel resolutions.
What video resolutions are available in NTSC mode?
In NTSC mode the camera can output 720×480, 704×480, 352×240, or 176×120 pixels.
How many digital alarm inputs and outputs does the device provide?
The CAM413 provides two digital alarm inputs and two digital alarm outputs.
What power options are available for the CAM427M camera?
The CAM427M can be powered by DC 12 V 2 A or AC 24 V, while the CAM427M‑PoE version uses a PoE injector compliant with IEEE 802.3at.
What is the maximum video resolution and frame rate supported?
The camera supports up to 1280 × 1024 at 10 fps and 640 × 480 at 30 fps.
