Featured SkyEra manuals
SkyEra TY-9XX+/-10NM-30.0W-25C-0.22NA-KB Laser Diode Module Data Sheet
The TY-9XX+/-10NM-30.0W-25C-0.22NA-KB is an uncooled fiber‑bundled laser diode module delivering up to 30 W output power. It supports standard central wavelengths of 915 nm, 940 nm and 975 nm and optional specialty fibers for uniform energy distribution, making it suitable for lighting and welding applications.
Key specifications include a 0.22 numerical aperture, 280 µm core diameter, operating current of 11.5 A, and operating temperature range of 15 °C to 55 °C. The datasheet also lists handling instructions such as eye‑safety precautions, ESD protection, and soldering guidelines for currents above 6 A.
Covers: Specification · Key Parameters · Application · Parameters · Dimension Diagram · Instructions
SkyEra T Y-0878.6 +/-01NM-30.0W-25C-200-0.22NA-T3S Laser Diode Module Data Sheet
The SkyEra T Y-0878.6 +/-01NM-30.0W-25C-200-0.22NA-T3S is an uncooled multimode laser diode module delivering 30 W output at a standard wavelength of 878.6 nm. It features a 0.22 numerical aperture fiber, parallel‑weld 2‑pin sealed packaging and complies with RoHS.
The datasheet provides detailed electrical parameters, mechanical dimensions, and safety instructions. Key values include output power, wavelength range, current and voltage limits, conversion efficiency and operating temperature ranges. Proper handling, ESD protection and soldering guidelines are also specified.
Covers: Specification · Key Parameters · Applications · Electrical Parameters · Dimensions · Safety Instructions
SkyEra TY-981+/ -01NM -60.0W -25C-105-0.22NA Laser Diode Module Data Sheet
The TY-981+/ -01NM -60.0W -25C-105-0.22NA is a 981 nm, 60 W uncooled multimode laser diode module with a 0.22 NA, 105 µm core fiber. It features high output power, narrow linewidth, RoHS compliance, and a parallel‑weld 2‑pin sealed package suitable for medical, pump source and material‑processing applications.
Key specifications include a centre wavelength of 981 nm, output power of 60 W, operating current up to 12 A, and operating temperature range of 20 °C–30 °C. The data sheet also provides handling instructions such as eye‑safety precautions, ESD protection, soldering limits, and storage temperature limits of –30 °C to +70 °C.
Covers: Specification · Key Parameters · Applications · Parameters · Dimension Diagram · Instructions
SkyEra TY-825NM+/ -05NM-60.0W-25C-CS Laser Diode Module Data Sheet
The TY-825NM+/ -05NM-60.0W-25C-CS is a 60 W uncooled single‑bar laser diode module operating at 825 nm. It uses AuSn bonding technology for low smile, high stability, and long lifetime, and complies with RoHS standards.
The sheet lists detailed electrical and optical specifications, recommended operating and storage temperatures, and safety instructions such as eye protection, ESD handling, and heat‑dissipation requirements. Typical applications include medical, printing, industrial, and pumping systems.
Covers: Specifications · Key Parameters · Applications · Dimension Diagram · Operating Instructions · Pinout
Latest SkyEra manuals
SkyEra TY-9XX+/-10NM-30.0W-25C-0.22NA-KB Laser Diode Module Data Sheet
Datasheet 2 pages · 173 KB · ENThe SkyEra TY-9XX+/-10NM-30.0W-25C-0.22NA-KB datasheet provides specifications for a 30 W uncooled fiber‑bundled laser diode module with 915‑975 nm…
SkyEra T Y-0878.6 +/-01NM-30.0W-25C-200-0.22NA-T3S Laser Diode Module Data Sheet
Datasheet 2 pages · 343 KB · ENThe SkyEra T Y-0878.6... laser diode module datasheet lists its 30 W output, 878.6 nm wavelength, electrical specs, dimensions and safety guidelines.
SkyEra TY-981+/ -01NM -60.0W -25C-105-0.22NA Laser Diode Module Data Sheet
Datasheet 2 pages · 347 KB · ENData sheet for SkyEra TY-981+/ -01NM -60.0W -25C-105-0.22NA 981 nm 60 W uncooled multimode wavelength‑stabilized laser diode module.
SkyEra TY-825NM+/ -05NM-60.0W-25C-CS Laser Diode Module Data Sheet
Datasheet 2 pages · 364 KB · ENThe SkyEra TY-825NM+/ -05NM-60.0W-25C-CS data sheet provides specifications, performance parameters, and usage guidelines for the 60 W 825 nm uncooled…
SkyEra TY-915+/-10NM-50.0W-25C-105.0NA Laser Diode Module Datasheet
Datasheet 2 pages · 831 KB · ENThe SkyEra TY-915+/-10NM-50.0W-25C-105.0NA datasheet provides specifications, dimensions, and handling instructions for the 915 nm 50 W uncooled multimode…
SkyEra TY-940+/-10NM-10.0W-25C-2PIN-105-0.22NA-HT Laser Diode Module Data Sheet
Datasheet 3 pages · 861 KB · ENData sheet for SkyEra TY-940+/-10NM-10.0W-25C-2PIN-105-0.22NA-HT 10W 940nm HT resistance uncooled multimode laser diode module.
