Featured Signal Generators manuals
RIGOL DG2041A/DG2021A Function/Arbitrary Waveform Generator Data Sheet
The DG2000 series function/arbitrary waveform generators from RIGOL use direct‑digital synthesis (DDS) to provide precise, low‑distortion signals. They support 10 standard waveforms, user‑defined arbitrary waveforms, and a range of modulation types (AM, FM, PM, PWM, FSK) with extensive I/O options including USB, LAN, RS‑232 and GPIB.
Key features include a 100 MSa/s sampling rate, 14‑bit vertical resolution, up to 512 kpts waveform length, and built‑in UltraWave software for editing and storing arbitrary waveforms. Ordering information, warranty details, and contact locations for service centers are also provided. This manual is written in Chinese.
Covers: Product Overview · Technical Specifications · Rise/Fall Time · Output Characteristics · Modulation Features · Ordering Information
Tektronix PPG1600, PPG3000, PPG3200 Series Pattern Generator Datasheet
The PatternPro® series programmable pattern generators provide up to four channels of stressed pattern generation for high‑speed Datacom testing, supporting data rates up to 32 Gb/s and a range of applications such as 100 Gigabit Ethernet, Fibre Channel, and DP‑QPSK testing. The instruments offer configurable output amplitude, jitter insertion options, and a built‑in adjustable clock source.
The datasheet lists detailed electrical specifications, optional features (HFJIT, LFJIT, ADJ, FXD), physical dimensions, and ordering information for the PPG1600, PPG3000, and PPG3200 models, as well as compatible accessories and power plug options.
Covers: Key performance specifications · Product description · Specifications · Clock outputs · Jitter insertion · Low frequency jitter insertion
HP 80824 Pulse Generator User Manual
This manual describes the HP 80824 pulse generator, a 250 MHz fast pulse source with variable transition times and ultra‑clean 50 Ω output impedance. It covers key specifications such as pulse width, repetition rate, output voltage options, and protection features.
The document includes sections on external input modes, trigger output configuration, general operating limits, and ordering information, helping users set up and operate the instrument safely and effectively.
Covers: Specifications · External Input · External‑Controlled Modes · Trigger Output · General · Ordering Information
Tektronix AWG500DB series Random waveform generator Manual
The AWG5000B series provides up to 1.2 GS/s sampling, 14‑bit vertical resolution and 2‑4 differential or single‑ended arbitrary waveform outputs. It supports high‑fidelity signal generation for wireless, imaging, data‑conversion and mixed‑signal test applications, with optional I/Q, IF and RF capabilities.
The manual includes hardware specifications, physical dimensions, environmental limits, connectivity options (USB, LAN, GPIB), software integration (RFXpress, MATLAB, MathCAD, Excel) and ordering details such as accessories, power‑plug options and service plans. This manual is written in Chinese.
Covers: Key Features and Advantages · Applications · Specifications · Physical Characteristics · Ordering Information · Options and Accessories
Latest Signal Generators manuals
RIGOL DG2041A/DG2021A Function/Arbitrary Waveform Generator Data Sheet
Datasheet 7 pages · 585 KB · ZHTechnical data sheet for RIGOL DG2041A and DG2021A function/arbitrary waveform generators.
Tektronix PPG1600, PPG3000, PPG3200 Series Pattern Generator Datasheet
Datasheet 12 pages · 1.8 MB · ENThe Tektronix PatternPro PPG1600, PPG3000, and PPG3200 series datasheet details specifications, features, and options for high‑speed programmable pattern…
HP 80824 Pulse Generator User Manual
User Manual 1 pages · 416 KB · ENThe HP 80824 pulse generator manual provides specifications, operation instructions, and configuration details for the 250 MHz fast pulse source.
Tektronix AWG500DB series Random waveform generator Manual
User Manual 8 pages · 882 KB · ZHThe Tektronix AWG5000B series manual details features, specifications, operation and ordering information for the arbitrary waveform generator.
Which document do I need?
Datasheet
Ratings, dimensions and ordering codes, for selection and design work.
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in Signal Generators manuals
What interfaces are supported by the DG2000 series?
The generators provide USB Device, USB Host, LAN, RS‑232 and GPIB interfaces, plus optional USB storage and web remote control.
From: RIGOL DG2041A/DG2021A Function/Arbitrary Waveform Generator Data Sheet
How many non‑volatile memory slots can store user‑defined arbitrary waveforms?
Four non‑volatile storage slots are available for user‑defined arbitrary waveforms.
From: RIGOL DG2041A/DG2021A Function/Arbitrary Waveform Generator Data Sheet
What is the typical inherent jitter of the PatternPro series?
The datasheet specifies low inherent jitter, with a typical RJ value of less than 250 fs.
From: Tektronix PPG1600, PPG3000, PPG3200 Series Pattern Generator Datasheet
What clock output frequencies are supported by the PPG3000 series?
The internal clock for the PPG3000 series can be set between 15 GHz and 30 GHz.
From: Tektronix PPG1600, PPG3000, PPG3200 Series Pattern Generator Datasheet
What is the maximum repetition rate of the HP 80824 pulse generator?
The generator can operate up to a repetition rate of 250 MHz.
What output voltage options are available?
It provides dual +5 V outputs and switch‑selectable ECL output levels.
