LAB.GRUPPEN C 10:4X service manual

Update: 29 September, 2023

Lab.gruppen amplifiers have earned a worldwide reputation for sonic excellence and durability in touring sound applications. The C 10:4X amplifier brings these qualities to a broad range of installed sound applications. It offers a combination of channel density, operating efficiency, and configuration flexibility, providing performance and cost-saving advantages. The output stage design, based on a patented Class D circuit topology, delivers high power levels with low distortion and efficiency levels of near 90%. The amplifier features a universal switching power supply with Power Factor Correction (PFC) and accepts a wide range of mains voltages. It includes unique features for specific application or load conditions, such as selectable input gain and a 35 Hz high pass filter. All channels are bridgeable.

Brand: LAB.GRUPPEN

File format: PDF

Size: 219 KB

MD5 Checksum: 819CC421A5AAFC98E5F0A8CE17D89FA8

Publication date: 06 August, 2012

Downloads: -

PDF Link: LAB.GRUPPEN C 10:4X service manual PDF

Download
