Featured TDK-Lambda manuals
TDK-Lambda DPP120-960 Series Power Supplies Product Leaflet
The DPP120‑960 Series provides 3‑phase DIN‑rail mounted power supplies in four output power options (120 W, 240 W, 480 W, 960 W). Each unit can be configured for 12 V, 24 V or 48 V outputs and accepts a wide AC input voltage range of 340 V to 575 V. Features include parallel operation, current sharing, over‑current, over‑voltage and over‑temperature protection, and compliance with EMC standards.
Physical specifications vary by model: the 120 W unit weighs about 800 g and measures 2.92 × 4.88 × 4.68 in, while the 960 W unit weighs 3400 g and measures 10.86 × 4.97 × 4.68 in. The series is UL508, UL60950‑1, EN60950‑1 and CE certified, and meets IEC vibration and shock requirements.
Covers: Features · Electrical Specifications · Physical Dimensions · Safety Approvals · Environmental Ratings · Model Selector
TDK-Lambda Medical Power Supplies User Manual
This manual provides detailed information for TDK‑Lambda’s medical‑grade power supplies, including the KM series (15‑40 W), CME150 (150 W), EFE‑300M (300 W), HWS series (30‑1500 W), SWS L series (1000 W) and Alpha series (1000‑1500 W). It covers input and output specifications, efficiency, safety certifications, mounting options, and warranty terms.
The document includes wiring diagrams, derating curves, environmental limits, and instructions for remote on/off control. It is intended for design engineers and service technicians who integrate these supplies into medical equipment.
Covers: KM Series · CME150 Series · EFE‑300M Series · HWS Series · SWS L Series · Alpha Series
Latest TDK-Lambda manuals
TDK-Lambda DPP120-960 Series Power Supplies Product Leaflet
Product Leaflet 2 pages · 152 KB · ENThe TDK‑Lambda DPP120‑960 Series offers 3‑phase DIN‑rail power supplies from 120 W to 960 W with a wide input range and built‑in protection features.
TDK-Lambda LZSA500 LZSA1000 LZSA1500 technology data
LZSA Series Single Output Industrial Power Supplies is an industrial power supply produced by Littelfuse. It features a rugged mechanical design, wide range of output adjustment, and reduced the need for custom outputs.
TDK-Lambda Medical Power Supplies User Manual
User Manual 44 pages · 2.7 MB · ENTechnical manual for TDK‑Lambda medical power supplies covering specifications, safety, mounting and operation.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in TDK-Lambda manuals
What input voltage range does the DPP120‑960 Series accept?
It accepts a wide AC input voltage range of 340 V to 575 V.
From: TDK-Lambda DPP120-960 Series Power Supplies Product Leaflet
What are the dimensions of the 960 W model?
The DPP960 model measures 10.86 × 4.97 × 4.68 in.
From: TDK-Lambda DPP120-960 Series Power Supplies Product Leaflet
