Featured Scanwill manuals
Scanwill MP-Series Hydraulic Pressure Intensifiers Data Sheet
The MP‑Series of hydraulic pressure intensifiers from Scanwill are designed for a wide range of industrial applications, including hydraulic workholding on machine tools, power packs, demolition tools and high‑pressure die‑casting equipment. Each model integrates high‑pressure valves and an optional pilot‑operated check valve (POV) to safely relieve pressure back to tank.
The document provides general material data, temperature limits, compatible fluids and filtration requirements, as well as detailed flow‑and‑pressure tables for each model (MP‑T, MP‑C, MP‑F, MP‑M, MP‑2000). Ordering codes and intensification ratio options are also listed, enabling easy selection for specific system needs.
Covers: Applications · General Data · MP‑T Pressure Intensifier · MP‑C Pressure Intensifier · MP‑F Pressure Intensifier · MP‑M Pressure Intensifier
Scanwill MP-M Pressure Intensifier Datasheet
The MP-M pressure intensifier is an in‑line hydraulic device designed for low‑pressure systems. It automatically increases supplied pressure to a higher end pressure (max. 800 bar) and can be installed in existing or new circuits using low‑pressure side valves.
The unit is offered with five standard intensification ratios (1.8, 3.4, 4.0, 5.0, 7.0) and optional ratios on request. All connections are 3/8" BSP, filtration must meet 10 µm nominal (max 19/16 ISO 4406), and flow/pressure values vary with fluid viscosity as shown in the table.
Covers: Pressure Intensifier · High Pressure Connection · Filtration Requirement · Flow & Pressure · Ordering Code
Latest Scanwill manuals
Scanwill MP-Series Hydraulic Pressure Intensifiers Data Sheet
Datasheet 12 pages · 2.9 MB · ENThe Scanwill MP-Series data sheet lists specifications, pressure ratings and application examples for the MP‑T, MP‑C, MP‑F, MP‑M and MP‑2000 hydraulic…
Scanwill MP-M Pressure Intensifier Datasheet
Datasheet 1 pages · 25 KB · ENThe Scanwill MP-M pressure intensifier raises low hydraulic pressure to up to 800 bar with selectable intensification ratios.
Which document do I need?
Datasheet
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in Scanwill manuals
What is the maximum pressure rating of the MP‑T pressure intensifier?
The MP‑T model is rated up to 800 bar (11 600 psi).
From: Scanwill MP-Series Hydraulic Pressure Intensifiers Data Sheet
Which fluids can be used with Scanwill MP‑Series intensifiers?
Only recognised hydraulic fluids and water‑glycol mixtures are approved; other fluids require factory consultation.
From: Scanwill MP-Series Hydraulic Pressure Intensifiers Data Sheet
What is the maximum output pressure of the MP‑M intensifier?
It can deliver up to 800 bar of pressure.
Which intensification ratios are offered as standard?
The standard ratios are 1.8, 3.4, 4.0, 5.0 and 7.0.
