Key facts
- Manuals
- 2
- Languages
- ZH
- Last added
- 2012-03-16
Featured Hangzhou立宇泰 manuals
Hangzhou Liyutai ARMSYS2410 Linux User Manual
This manual explains how to set up the hardware and software environment for the ARMSYS2410 board, including installing the cross‑compiler toolchain, configuring the kernel, and preparing the root file system. It also covers serial port setup, JTAG bootloader flashing, and network communication via Ethernet.
Additional sections provide example programs, driver resources, and network services such as Telnet, FTP, and a built‑in web server that can control the board’s LEDs. The document assumes a Red Hat Linux 9.0 host environment. This manual is written in Chinese.
Covers: 内容综述 · 硬件环境 · 软件环境 · 串口的使用 · JTAG 的使用 · 网络通讯的使用
Liyutai S3C44B0X Datasheet
The S3C44B0X microcontroller includes an internal memory controller that provides two sets of necessary memory control signals for external memory operations. It supports up to 8 memory banks with a total address space of 236 MB (32 MB per bank) and programmable bus widths of 8, 16, or 32 bits.
Endianness is selectable via the ENDIAN pin (0 = little‑endian, 1 = big‑endian). Bank configuration registers (BANKCONn) allow setting bus width, wait states, and memory type for each bank. The REFRESH register controls DRAM/SDRAM refresh enable and mode, while the SCLKEN bit can reduce power consumption during SDRAM accesses. This manual is written in Chinese.
Covers: Overview · Memory Controller · Endianness · Bank Configuration · Register Definitions · Refresh Control
Latest Hangzhou立宇泰 manuals
Hangzhou Liyutai ARMSYS2410 Linux User Manual
User Manual 46 pages · 2 MB · ZHLinux development and usage guide for the Hangzhou Liyutai ARMSYS2410 embedded board.
Liyutai S3C44B0X Datasheet
Datasheet 5 pages · 378 KB · ZHThe Liyutai S3C44B0X datasheet provides specifications, memory controller features, and register definitions for the S3C44B0X microcontroller.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Datasheet
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in Hangzhou立宇泰 manuals
What command starts the built‑in web server on ARMSYS2410?
Run /etc/rc.d/init.d/httpd start to launch the web server.
How can I flash the bootloader onto ARMSYS2410 using JTAG?
Connect the PC parallel port to the JTAG board with a 20‑pin ribbon cable and use the JTAG interface as described in section 4 to program the bootloader.
How many memory banks does the S3C44B0X have?
The S3C44B0X has a total of eight memory banks.
How is endianness selected on the S3C44B0X?
Endianness is selected via the ENDIAN pin: 0 for little‑endian and 1 for big‑endian.
