Featured Beijing天能继保电力 manuals
Beijing Skypower DSI 5172 User Manual
The DSI 5172 comprehensive measurement and control device, developed by Beijing Skypower, is designed for use in power substations of various voltage levels. It integrates remote measurement, remote signaling, and remote control functions, supporting IEC 61850 and IEC 60870‑5‑103 communication protocols.
The manual details the hardware architecture, including a Freescale ColdFire MCF5275 CPU, 32 MB DDR, 16 MB Flash, and 2 MB NVRAM, as well as the device’s environmental ratings, power requirements, and programming capabilities. It also provides installation, operation, and maintenance procedures. This manual is written in Chinese.
Covers: Overview · Technical Parameters · Device Hardware · Operation Principle · Usage Instructions · Storage and Warranty
TianNeng DSI5152 Motor Protection and Measurement Device User Manual
The DSI5152 is a motor protection and measurement device designed for 3 kV ~ 10 kV medium‑high voltage asynchronous motors. It can be installed locally in a switchgear cabinet or mounted on a panel and complies with IEC 61850 modeling requirements for smart grid applications.
The unit features a high‑performance CPU, dual Ethernet interfaces, a large LCD screen with up to 18 programmable indicator lights, and extensive protection functions such as differential, over‑current, over‑voltage, and fault recording. It operates in temperatures from –10 °C to +50 °C, with storage limits of –25 °C to +70 °C, and meets strict insulation and electromagnetic interference standards. This manual is written in Chinese.
Covers: Overview · Applicable Range · Main Functions · Technical Parameters · Rated Parameters · Power Consumption
Tianneng DSI 5163 Bus PT Parallel Insulation Monitoring Device User Manual
The DSI 5163 is a bus PT parallel insulation monitoring device designed for voltage levels up to 6 kV in neutral‑grounded or resistance‑grounded systems. It offers insulation monitoring, PT line break detection, PT parallel operation, GPS time synchronization, and extensive communication capabilities based on IEC 61850.
The manual covers the device’s hardware architecture, technical parameters, installation, operation, maintenance, and troubleshooting. It includes detailed wiring diagrams, configuration procedures, and safety guidelines to ensure reliable performance in substation environments. This manual is written in Chinese.
Covers: Overview · Applicable Scope · Main Functions · Technical Parameters · Device Hardware · Working Principle
Skypower Electric Technology DSI5151 Motor Protection and Measurement Unit User Manual
The DSI5151 motor protection and measurement unit is designed for 3 kV ~ 10 kV medium‑high voltage asynchronous motors. It complies with IEC 61850‑7‑4 modeling requirements and supports IEC 61850 and IEC 60870‑5‑103 communication protocols. The device can be installed in switchgear cabinets or as a standalone screen unit.
The unit offers a wide range of protection functions (fast‑trip, over‑current, inverse‑time, long‑start‑time, negative‑sequence, overload, over‑heat, zero‑sequence, grounding, over‑voltage, low‑voltage, internal protection, TV/TA line‑break detection) and measurement capabilities, with a programmable graphical interface, dual‑Ethernet, and optional optical fiber links. It includes a high‑performance VxWorks‑based CPU, LCD display, and up to 18 programmable indicator LEDs. This manual is written in Chinese.
Covers: Overview · Applicable Scope · Main Functions · Technical Parameters · Device Hardware · Operation Principle
Latest Beijing天能继保电力 manuals
Beijing skypower electric technology DSI5156/5166/5167 Manual
Beijing Skypower DSI 5172 User Manual
User Manual 23 pages · 937 KB · ZHThe DSI 5172 is a comprehensive measurement and control device for substations, and this manual provides its features, specifications, and operation…
Beijing skypower electric technology DSI5131 Manual
Beijing skypower electric technology DSI5631 Manual
TianNeng DSI5152 Motor Protection and Measurement Device User Manual
User Manual 46 pages · 1.2 MB · ZHThe TianNeng DSI5152 motor protection and measurement device manual provides overview, specifications, installation, operation, and maintenance instructions.
Tianneng DSI 5163 Bus PT Parallel Insulation Monitoring Device User Manual
User Manual 23 pages · 970 KB · ZHUser manual for the Tianneng DSI 5163 device that monitors bus PT parallel insulation and provides protection, measurement and communication functions.
Skypower Electric Technology DSI5151 Motor Protection and Measurement Unit User Manual
User Manual 43 pages · 1.1 MB · ZHThis manual provides installation, operation, and protection settings for the Skypower DSI5151 motor protection and measurement unit.
TianNeng Jibao DSI 5153 Motor Protection Device User Manual
User Manual 39 pages · 1.1 MB · ZHThis manual describes the DSI 5153 motor protection and monitoring device by TianNeng Jibao, covering features, specifications, installation, and operation.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in Beijing天能继保电力 manuals
How many analog measurement channels are available?
The device provides 12 analog measurement channels.
What are the power supply requirements?
It can be powered from a DC source of 220 V or 110 V (or AC 220/110/380 V).
What voltage levels is the DSI5152 suitable for?
It is suitable for medium‑high voltage asynchronous motors rated from 3 kV to 10 kV.
From: TianNeng DSI5152 Motor Protection and Measurement Device User Manual
What are the rated DC input voltage options?
The device can be powered by either 220 V or 110 V DC, as specified on the order.
From: TianNeng DSI5152 Motor Protection and Measurement Device User Manual
What is the rated DC voltage of the DSI 5163?
The device can be supplied with either 220 V or 110 V DC, as specified on the order.
From: Tianneng DSI 5163 Bus PT Parallel Insulation Monitoring Device User Manual
What are the rated voltage and current specifications?
The unit can be powered from a DC source of 220 V (or 110 V) and operates on an AC supply of 100 V (or 100/3 V) with a rated current of 5 A (or 1 A), as specified on the order.
From: Skypower Electric Technology DSI5151 Motor Protection and Measurement Unit User Manual
