Renishaw models by category
Featured Renishaw manuals
Renishaw HPPA, TSI 2, TSI 2-C Installation and User Guide
The HPPA (High‑precision pulldown arm) together with the TSI 2 and TSI 2‑C interfaces form a tool‑setting solution for high‑precision measurement of cutting tools, primarily on CNC turning machines. The system includes a manual arm, probe, stylus, and interface units that connect to the machine controller.
The document covers everything needed to install the arm and interface, wiring diagrams, probe connection details, tool‑setting procedures, calibration, routine maintenance, fault‑finding, and a complete parts list. Safety instructions, recommended power supplies, and grounding requirements are also provided.
Covers: Before you begin · Intended use · Safety · System kit · HPPA specification · TSI 2 / TSI 2‑C specification
Renishaw ATOM™ M-9693-9728-03-B Installation Guide
This guide provides detailed instructions for installing the ATOM™ high‑precision linear encoder system, including product compliance, storage conditions, and system‑level installation overview. It covers both RTLF steel‑tape and RCLC glass scales, application methods, and the use of reference fixtures and end caps.
The document also describes system connections, read‑head mounting and adjustment, calibration procedures, electrical wiring, output specifications, and a troubleshooting section to resolve common LED and signal issues. This manual is written in Chinese.
Covers: Product Compliance · Storage and Use · System Installation Overview · RTLF Steel Tape Scale Installation · RCLC Glass Scale Installation · System Connection
Renishaw TRS2 Non‑Contact Tool Breakage Detection System Product Leaflet
The TRS2 is a single‑side, non‑contact laser system that monitors solid tools in vertical, horizontal, gantry and multi‑function machines. It is mounted outside the machining area, saving valuable space, and uses a laser beam reflected from the rotating tool to assess its condition.
When a broken tool is detected, the system issues an alarm and can stop the machine or trigger an automatic tool change, dramatically reducing non‑productive time and scrap rates while improving overall process reliability. This manual is written in Chinese.
Covers: System Overview · In‑process Control · Single‑Side Laser Detection · ToolWise™ Identification Technology · Key Features · Value Proposition
Renishaw Product Range Catalog
Renishaw’s product range covers a wide variety of metrology solutions designed to control processes, improve quality and raise productivity. The catalogue includes probe systems for CMMs and CNC machine tools, performance measurement and calibration systems, high‑speed optical and magnetic encoders, a broad selection of styli, and spectroscopy instruments for material analysis.
The document also highlights custom‑designed solutions, service support locations worldwide, and technical details such as resolution capabilities and measurement speeds for key products like the XL‑80 laser system and RG2 optical linear encoders.
Covers: Probe systems for CNC machine tools · Performance measurement and calibration systems · Manual and motorised heads for CMMs · Touch‑trigger and scanning probe systems · Position encoders · Styli and spectroscopy
Latest Renishaw manuals
Renishaw HPPA, TSI 2, TSI 2-C Installation and User Guide
User Manual 52 pages · 2.6 MB · ENThis guide provides installation, operation, safety, maintenance, and specifications for Renishaw HPPA and TSI 2/TSI 2-C tool‑setting system.
Renishaw ATOM™ M-9693-9728-03-B Installation Guide
Installation Guide 39 pages · 7.5 MB · ZHInstallation guide for the Renishaw ATOM™ linear encoder system covering compliance, storage, installation steps, calibration and troubleshooting.
Renishaw TRS2 Non‑Contact Tool Breakage Detection System Product Leaflet
Product Leaflet 5 pages · 1.1 MB · ZHThe Renishaw TRS2 non‑contact tool breakage detection system provides fast, reliable laser‑based monitoring to reduce waste and increase machining…
Renishaw Product Range Catalog
Product Leaflet 8 pages · 324 KB · ENAn overview of Renishaw's probe systems, measurement equipment, encoders, styli and spectroscopy solutions for industrial metrology.
RENISHAW XL-80 laser Interference Instrument system Manual
RENISHAW TRS1 Non-contact Type Tool breakage test system specifications Manual
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Installation Guide
Mounting, wiring and first power-up. Read it before the hardware goes in.
Questions answered in Renishaw manuals
What safety precautions must be taken before installing the HPPA system?
Power must be switched off and the power supply to the TSI 2 or TSI 2‑C disconnected. The installer should also follow local electrical safety requirements and ensure proper grounding.
From: Renishaw HPPA, TSI 2, TSI 2-C Installation and User Guide
What is the purpose of the HPPA system?
It provides a high‑precision tool‑setting solution that allows manual presentation of a probe into the machine’s working envelope for accurate measurement of cutting tools.
From: Renishaw HPPA, TSI 2, TSI 2-C Installation and User Guide
What power supply voltage is required for the ATOM encoder?
The encoder requires a 5 V ± 10 % power supply.
What are the storage temperature limits for the encoder?
The device can be stored from –20 °C to +70 °C.
How does the TRS2 detect a broken tool?
It emits a laser beam that is reflected by the rotating tool; the reflected intensity is analyzed by the ToolWise™ technology to determine if the tool is intact.
From: Renishaw TRS2 Non‑Contact Tool Breakage Detection System Product Leaflet
What happens when a broken tool is detected?
The system generates a “tool breakage” alarm and can stop the machine or trigger an automatic tool change to replace the tool.
From: Renishaw TRS2 Non‑Contact Tool Breakage Detection System Product Leaflet
