Proline models by category
Featured Proline manuals
Endress+Hauser t-mass 65 User Manual
This manual covers the safe use of the Proline t‑mass 65 mass flow meter, including required safety measures, compliance with standards such as EN1010‑1 and HN61326/A, and guidelines for proper installation and wiring. It also details operating procedures, calibration steps, and cleaning methods to ensure accurate measurement of gas and oil flow.
Additional sections describe fault diagnosis, repair procedures, technical parameters, and required accessories. The document includes tables for terminal assignments, HART communication, and specifications such as power supply, temperature range, and pressure limits. This manual is written in Chinese.
Covers: Safety Guidelines · Installation Guide · Operation Instructions · Calibration · Cleaning and Maintenance · Fault Diagnosis
Endress+Hauser Promass 80F/80M/83F/83M User Manual
The Promass series (80F, 80M, 83F, 83M) is a universal, multivariable Coriolis mass flow measurement system for liquids and gases. It measures mass flow, density, temperature and can calculate additional variables such as concentration. The sensor design is modular and can be integrated or separated from the transmitter.
The manual provides detailed information on measurement principles, sensor construction, input and output signals, communication interfaces (PROFIBUS PA, MODBUS RS485, FOUNDATION Fieldbus), safety certifications (ATEX, FEM, CSA) and ordering codes. Installation, wiring diagrams and configuration options are also covered. This manual is written in Chinese.
Covers: Measurement Principle · System Design · Sensor Types · Input Signals · Output Signals · Communication Interfaces
Endress+Hauser Proline Promass 80/80M/83/83M User Manual
The Proline Promass series measures multiple process variables such as mass flow, density, temperature and concentration simultaneously. It uses a modular design with optional software packages for batch control and concentration measurement, and includes built‑in fault diagnosis and data backup.
The system consists of a transmitter and a sensor, available in integrated or separated configurations. Various sensor materials (stainless steel, titanium, alloy) and pipe diameters are offered, and the device supports numerous communication interfaces such as PROFIBUS PA, MODBUS, FOUNDATION Fieldbus and HART, with electrical isolation for inputs and outputs. This manual is written in Chinese.
Covers: 特点 · 测量系统 · 传感器类型 · 接线端子分配 · 输出信号 · 接口
Endress+Hauser PROline Promag 10 W Electromagnetic Flow Meter Manual
The PROline Promag 10 W is an electromagnetic flow meter designed for measuring liquids with a conductivity of at least 50 µS/cm, suitable for drinking water, wastewater and sludge applications. It supports nominal pipe diameters from DN 25 to DN 600 and can operate in harsh environments with an IP68 protection rating.
The manual covers functional design, measurement principle, mechanical construction, electrical wiring, power supply options, output signals (current and pulse), installation procedures, safety and certification information, as well as maintenance and troubleshooting guidance. This manual is written in Chinese.
Covers: Functional Design and System · Measurement Principle · Mechanical Structure · Power Supply and Electrical Wiring · Output Signals · Installation Instructions
Latest Proline manuals
Endress+Hauser t-mass 65 User Manual
User Manual 98 pages · 3.7 MB · ZHThe Endress+Hauser t-mass 65 user manual provides safety, installation, operation, and maintenance instructions for the mass flow meter.
Endress+Hauser Promass 80F/80M/83F/83M User Manual
User Manual 64 pages · 2.5 MB · ZHThe Endress+Hauser Promass 80F, 80M, 83F and 83M manual describes the Coriolis mass flow measurement system, its features, installation, wiring and…
Endress+Hauser Proline Promass 80/80M/83/83M User Manual
User Manual 64 pages · 2.6 MB · ZHThe Endress+Hauser Proline Promass 80/80M/83/83M user manual describes features, measurement principle, installation, wiring, and specifications for the…
Endress+Hauser PROline Promag 10 W Electromagnetic Flow Meter Manual
User Manual 32 pages · 486 KB · ZHThe Endress+Hauser PROline Promag 10 W electromagnetic flow meter manual provides specifications, installation, wiring, and operation instructions.
Endress+Hauser PROLINE PROMASS40 Coriolis Mass Flowmeter Operation Guide
User Manual 69 pages · 703 KB · ZHOperation guide for the Endress+Hauser PROLINE PROMASS40 Coriolis mass flowmeter covering installation, wiring, operation, debugging and maintenance.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in Proline manuals
What safety standards does the t‑mass 65 comply with?
It complies with EN1010‑1, HN61326/A, NE21, NE43 and NE53 standards.
What is the recommended operating temperature range?
The device can operate between –20 °C and +60 °C.
What is the maximum process pressure rating?
The device can operate at a process pressure of up to 350 bar.
What is the temperature range for the sensor?
The sensor can measure media temperatures up to +350 °C.
Which pipe diameters can be measured with this flow meter?
It supports nominal diameters from DN 25 to DN 600.
From: Endress+Hauser PROline Promag 10 W Electromagnetic Flow Meter Manual
Which safety standards does the PROLINE PROMASS40 comply with?
It meets the EN61010, EN61326/A1 (EMC) and NAMUR NE21/43 standards for electrical safety and electromagnetic compatibility.
From: Endress+Hauser PROLINE PROMASS40 Coriolis Mass Flowmeter Operation Guide
