Featured NAV manuals
NAV Technology NV-MC311 Digital Compass Module Manual
The NV-MC311 digital compass module uses a magnetoresistive sensor and a two‑axis tilt sensor to deliver heading information. It can operate accurately even when tilted up to 70°, and includes an automatic calibration routine to compensate for magnetic interference.
The manual lists the module's physical dimensions, electrical characteristics, performance specifications, and recommended operating conditions, as well as typical application areas such as aviation, marine navigation, radar, antenna installation, and vehicle detection. This manual is written in Chinese.
Covers: Application range and features · Performance specifications · Physical dimensions · Electrical characteristics · Operating temperature and storage · Communication interface
NAV Technology NV-MC316 Digital Compass Datasheet
The NV-MC316 is a digital compass module that uses a magnetoresistive sensor and a two‑axis tilt sensor to deliver precise heading information even when tilted up to 40°. It includes an automatic calibration routine to compensate for magnetic disturbances and can output pitch, roll, and heading in NMEA0183 format via an RS‑232 interface.
The device operates from a 5 V nominal supply (6 V–15 V range) with a typical current draw of 75 mA, and offers a dynamic magnetic field range of up to ±60 000 nT. It features a 20 Hz update rate, low power consumption, and a compact size suitable for aviation, marine, robotics, and vehicle applications.
Covers: Features · Performance Specifications · Physical Characteristics · Electrical Characteristics · Interface and Communication · Operating Conditions
Latest NAV manuals
NAV Slim portable cars navigation system Manual
This document provides the user manual for GPSmile62 NAV Slim portable car navigation system, including version information, safety precautions, warranty statement, and technical support. The navigation system is manufactured and sold by HOLUX Technology, Inc., and it offers portability and reliability.
NAV Technology NV-MC311 Digital Compass Module Manual
User Manual 1 pages · 56 KB · ZHThe NAV Technology NV-MC311 digital compass module manual provides specifications, features, and usage details for the magnetic sensor‑based heading device.
NAV Technology NV-MC316 Digital Compass Datasheet
Datasheet 1 pages · 42 KB · ENThe NAV Technology NV-MC316 digital compass provides high‑accuracy heading, pitch and roll data with RS‑232 output and low power consumption.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Datasheet
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in NAV manuals
What are the physical dimensions of the NV-MC311 module?
The module measures 25.4 mm × 36.8 mm × 1.6 mm (L × W × H).
What voltage and current does the NV-MC311 require?
It operates from a 5.0 VDC supply and draws up to 75 mA at that voltage.
What interface does the NV-MC316 use to output data?
It uses an RS‑232 serial port with selectable baud rates from 1200 to 38400 bps.
What is the required supply voltage for the NV-MC316?
The module is powered by a 5 VDC nominal supply and can operate from 6 V to 15 VDC.
