Key facts
- Manuals
- 4
- Languages
- EN
- Last added
- 2012-05-11
Featured Modular manuals
Chroma 62000B Series Modular DC Power Supply Manual
The 62000B Series modular DC power supplies are designed for burn‑in, plating and electrolysis applications such as LCD panels, DC‑DC converters, inverters and battery chargers. They offer N+1 redundancy, hot‑swap capability, remote ON/OFF and CAN‑bus programmable control, and can be paralleled for up to 120 kW output.
Key features include a voltage range of 1 V‑150 V, current up to 2000 A (system), high power density, built‑in power‑factor correction (>0.98), and optional graphic soft panels, Ethernet and CAN interfaces. The Control & Supervisor Unit provides local and remote monitoring, current sharing, and protection functions such as OVP, OCP and OTP.
Covers: Key Features · Panel Description · Control Method for Paralleled Operation · Specifications · Control & Supervisor Unit · Ordering Information
Latest Modular manuals
Modular PE terminals handbook
TS 32 / PA modular PE terminals have ATEX certification and can be used in hazardous area applications.
Modular feed-through terminal handbook
TS 32 / PA Modular feed-through terminal
Modular Media Converter Center System KC-1300 Operation Manual
This document is the operation manual for the KC-1300 Modular Media Converter Center System. It provides detailed information and operating instructions for the product.
Chroma 62000B Series Modular DC Power Supply Manual
User Manual 6 pages · 626 KB · ENThe Chroma 62000B Series Modular DC Power Supply manual details features, specifications, operation and control options.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in Modular manuals
What is the maximum output power of the 62000B series?
The system can deliver up to 120 kW of output power when multiple mainframes are paralleled.
How many mainframes can be paralleled together?
Up to fourteen mainframes can be paralleled, with current sharing and CAN‑bus control for bulk power applications.
