LAMMIN LLP6993-01B/CL Power Dimmer Manual
The LAMMIN LLP6993-01B/CL is a power dimmer that can be controlled by a rotary knob or a 1‑10 V DC signal. It supports incandescent, 230 V halogen, and low‑voltage halogen lamps with a maximum output of 3 kW (01BL) or 4 kW (01CL). Features include an emergency manual button, status indicator, multiple temperature protections, accurate dimming ratio, and DIN‑rail mounting.
The manual details installation dimensions, terminal layout, wiring connections, and an electrical wiring diagram. Safety instructions cover ventilation, overload prevention, moisture and dust protection, and proper grounding. Emergency operation is performed by holding the manual button, which causes the indicator to flash rapidly and the output brightness to cycle from 0 % to 100 %. This manual is written in Chinese.
Covers: Product Overview · Features · Technical Specifications · Installation Dimensions · Terminal Connections · Electrical Wiring Diagram
Latest LAMMIN manuals
LAMMIN LLP6993-01B/CL Power Dimmer Manual
User Manual 2 pages · 299 KB · ZHThe LAMMIN LLP6993-01B/CL Power Dimmer Manual provides product overview, specifications, wiring diagram, installation, and safety guidelines.
