Featured GL-SX450B中型音视频矩阵系统 manuals
Guanlin GL-SX450B Medium Audio Video Matrix System User Manual
The GL‑SX450B is a modular audio‑video matrix designed for security systems in shopping centers, offices, banks and similar environments. It offers a flexible configuration with up to 64 audio‑video inputs and 16 outputs per unit, expandable to 256 inputs and 64 outputs, and supports multiple alarm I/O channels and RS‑485 communication compatible with Pelco‑D, Pelco‑P, Philips and Bosch protocols.
This manual details the technical specifications, main features, component layout, and provides step‑by‑step installation and operation guidance. It also includes information on system expansion, wiring diagrams, and the use of the optional GUANLIN control keyboard (GL‑CU450). This manual is written in Chinese.
Covers: Technical Specifications · Main Features · Main Components · System Installation and Operation · Matrix Capacity · Alarm Input Configuration
Latest GL-SX450B中型音视频矩阵系统 manuals
Guanlin GL-SX450B Medium Audio Video Matrix System User Manual
User Manual 7 pages · 292 KB · ZHThe Guanlin GL-SX450B medium audio‑video matrix system manual provides specifications, installation steps, and operation instructions for the modular AV…
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in GL-SX450B中型音视频矩阵系统 manuals
What is the maximum number of audio‑video inputs a single GL‑SX450B unit can handle?
A single unit supports up to 64 audio‑video inputs and 16 outputs.
From: Guanlin GL-SX450B Medium Audio Video Matrix System User Manual
How can the GL‑SX450B system be expanded beyond the single‑unit capacity?
Modules can be stacked to increase capacity to 256 audio‑video inputs and 64 outputs, and to 256 alarm inputs and 128 alarm outputs.
From: Guanlin GL-SX450B Medium Audio Video Matrix System User Manual
