Featured EUCHIPS manuals
Euchips EUMA0405 Programmable Phase‑Cut & 0‑10V Dimmer Controller User Manual
This manual provides a complete overview of the EUMA0405 series programmable phase‑cut and 0‑10V dimmer controller, including its MOS‑FET based output stage, supported control protocols (DMX‑512/RDM, DALI, EU‑BUS) and manual operation. It describes the LCD menu system, key functions, and how to configure control and output modes.
Detailed sections cover hardware interfaces, wiring diagrams, emergency‑switch operation, system settings such as time and backlight, and step‑by‑step instructions for creating and managing up to eight timed events. Application examples illustrate typical lighting scenarios for venues like hotels, schools, and conference rooms. This manual is written in Chinese.
Covers: Overview · Product Features · Technical Specifications · Interface Introduction · LCD Main Interface · Control Mode
Euchips DALI-P03 Touch Panel Controller User Manual
The DALI-P03 is a touch‑sensitive panel for controlling DALI lighting systems. It supports DALI Type 8 colour temperature, broadcast control, and can store up to four scenes. The panel features a blue LED button indicator, a glass front, and DIP‑switch configurable group IDs.
The manual explains how to adjust brightness and colour temperature by rotating the touch ring, how to save and recall scenes, and provides step‑by‑step installation instructions for mounting the controller in an electrical box and connecting the wiring.
Covers: Product Features · Technical Parameters · Brightness Adjustment · Color Temperature Control · Scene Management · Interface Introduction
EUCHIPS ESD20310X/ESD21310X/ESD22310X Installation Manual
This guide provides step‑by‑step installation instructions for the EUCHIPS ESD20310X, ESD21310X and ESD22310X LED tube lights. It emphasizes safety precautions such as avoiding direct eye exposure to LED light and ensuring proper grounding to prevent hazardous situations.
The manual lists the three available tube lengths (125 mm, 150 mm, 175 mm) and technical data such as operating voltage (100‑240 VAC) and power consumption. Contact information for EUCHIPS Shanghai office is also included. This manual is written in Chinese.
Covers: Installation Instructions · Safety Precautions · Technical Specifications · Contact Information
Latest EUCHIPS manuals
Euchips EUMA0405 Programmable Phase‑Cut & 0‑10V Dimmer Controller User Manual
User Manual 14 pages · 1.5 MB · ZHThe Euchips EUMA0405 manual explains features, technical specs, wiring, LCD interface, control modes, and event programming for the programmable phase‑cut…
Euchips DALI-P03 Touch Panel Controller User Manual
User Manual 2 pages · 7.7 MB · ENThe Euchips DALI-P03 User Manual provides instructions for operating the touch‑panel lighting controller, including brightness, color temperature, scene…
EUCHIPS ESD20310X/ESD21310X/ESD22310X Installation Manual
Installation Guide 1 pages · 134 KB · ZHInstallation manual for EUCHIPS ESD20310X, ESD21310X and ESD22310X LED tube lights, including safety warnings and wiring specs.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Installation Guide
Mounting, wiring and first power-up. Read it before the hardware goes in.
Questions answered in EUCHIPS manuals
How many events can be stored in the controller?
The system can store up to eight events.
From: Euchips EUMA0405 Programmable Phase‑Cut & 0‑10V Dimmer Controller User Manual
What happens when the backlight is set to ON?
When the backlight is ON, the LCD stays lit for 60 seconds of inactivity, then the display goes to sleep mode.
From: Euchips EUMA0405 Programmable Phase‑Cut & 0‑10V Dimmer Controller User Manual
How do you adjust the brightness?
Touch the ring and turn clockwise to increase brightness or anti‑clockwise to decrease; the range is 5 % (darkest) to 100 % (brightest).
How many scenes can be saved and recalled?
The controller can store up to four scenes, which can be recalled by briefly pressing the SCENE button.
What safety precautions are required when installing the ESD series lights?
Avoid looking directly at the LED light, ensure proper grounding, keep the installation area free of excess vibration, and follow all warning notices to prevent injury or damage.
From: EUCHIPS ESD20310X/ESD21310X/ESD22310X Installation Manual
What tube lengths are available for the ESD20310X series?
The series is offered in three lengths: 125 mm, 150 mm, and 175 mm.
From: EUCHIPS ESD20310X/ESD21310X/ESD22310X Installation Manual
