Aruba models by category
Featured Aruba manuals
Aruba Instant On 2.2.0 User Guide
This guide provides step‑by‑step instructions for deploying Aruba Instant On devices, including access points and switches, in wireless‑only, wired‑only, or mixed environments. It covers initial provisioning, network configuration, and use of the Instant On mobile and web applications.
Additional sections describe advanced features such as PoE power scheduling, DNS settings, firmware upgrades, alert notifications, and a built‑in troubleshooting assistant to help administrators resolve common issues. This manual is written in Chinese.
Covers: Supported Devices · New Features and Hardware Platform · Deployment Concepts · Network Configuration · Device Management · Firmware Upgrade
Aruba CX Switch Basic Operation Guide
The Aruba CX Switch Basic Operation Guide introduces the fundamental procedures for setting up, operating, and managing Aruba CX series switches. It explains how to prepare the device, power it on or off, and perform basic CLI and Web UI tasks.
The document covers a wide range of topics, including console connection methods, login management, VLAN configuration, VSF/VSX clustering, routing, authentication, ACLs, and Smart Link features, providing step‑by‑step commands and examples for each function. This manual is written in Japanese.
Covers: はじめに (Introduction) · 情報リソース (Information Resources) · 設定の準備・起動/停止/再起動 (Setup and Power Management) · 基本操作・コマンド (Basic Operations and Commands) · ログイン管理 (Login Management) · 設定・ファイル管理 (Configuration and File Management)
Aruba AP-120/AP-121 Data Sheet
Aruba AP-120 and AP-121 are indoor 802.11n access points designed for low‑density environments. They can be ceiling‑mounted or rack‑mounted and provide up to 300 Mbps link rate with a single 3x3 MIMO radio. Both models support dual‑band 2.4‑GHz/5‑GHz operation and include Aruba’s adaptive RF management and spectrum analysis features for reliable performance.
The devices offer dual 100/1000BASE‑T Ethernet ports with PoE (802.3af, 802.3at, PoE+), optional external antennas for the AP-120, and integrated omnidirectional antennas for the AP-121. They are certified for worldwide regulatory standards and operate from 0 °C to 50 °C with a storage range of –40 °C to +70 °C. This manual is written in Chinese.
Covers: Product Overview · Supported Frequency Bands · Antenna Options · Power and PoE · Physical Dimensions · Operating Environment
Aruba AP-120 and AP-121 Access Point Data Sheet
The Aruba AP-120 and AP-121 are indoor 802.11n access points designed for low‑density environments. They can be ceiling‑mounted or rack‑mounted and offer dual‑band 2.4 GHz and 5 GHz operation with 3×3 MIMO for up to 300 Mbps link rates. Both models support PoE (802.3af/at) and have two 100/1000 BASE‑T Ethernet ports.
AP‑120 features detachable RP‑SMA antennas, while AP‑121 uses integrated omnidirectional antennas with gains of 3.2 dBi (2.4 GHz) and 5.2 dBi (5 GHz). The devices are certified for worldwide regulatory standards and come with Aruba’s lifetime warranty. This manual is written in Chinese.
Covers: General Overview · Radio Frequency Specifications · Antenna Options · Power and PoE · Ethernet Interfaces · Physical Dimensions
Latest Aruba manuals
Aruba Instant On 2.2.0 User Guide
User Manual 86 pages · 3.5 MB · ZHThe Aruba Instant On 2.2.0 User Guide explains setup, management, monitoring and troubleshooting for small‑business networks.
Aruba CX Switch Basic Operation Guide
User Manual 120 pages · 4.4 MB · JAThis guide provides basic operation and configuration instructions for Aruba CX series switches.
Aruba AP-120/AP-121 Data Sheet
Datasheet 4 pages · 423 KB · ZHThe Aruba AP-120 and AP-121 are indoor 802.11n access points with dual‑band 3x3 MIMO, PoE support, and up to 300 Mbps throughput.
Aruba AP-120 and AP-121 Access Point Data Sheet
Datasheet 4 pages · 707 KB · ZHData sheet for Aruba AP-120 and AP-121 indoor 802.11n access points with specs, power options and certifications.
Aruba AP-105 Access Point Data Sheet
Datasheet 4 pages · 694 KB · ZHThe Aruba AP-105 data sheet details specifications, features, and installation options for this indoor dual‑band 802.11n access point.
Aruba AP-124 and AP-125 Access Point Manual
User Manual 4 pages · 710 KB · ZHThe manual provides specifications, installation instructions, and feature details for Aruba AP-124 and AP-125 indoor 802.11n access points.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Datasheet
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in Aruba manuals
How can I enable email notifications for alerts?
In the Instant On web app, enable the email notification option on the alerts page.
What should I do if a firmware upgrade fails?
The device will continue running the previous firmware; the upgrade will be retried at the next scheduled time.
What management methods are available for Aruba CX switches?
Aruba CX switches can be managed via the AOS‑CX command‑line interface, the Web UI, the REST API, and Aruba Central (except for the CX 10000 and 9300 series).
What PoE standards does the Aruba AP-120 support?
The AP-120 supports 48 V DC PoE via 802.3af, 802.3at, or PoE+.
What is the maximum transmit power for the 2.4 GHz band?
The maximum transmit power is 23 dBm, subject to local regulatory limits.
What is the maximum data rate of the AP‑120/121?
The access points support up to 300 Mbps link rate using 802.11n MCS15.
