Featured 20 manuals
KeXey 20 Modular Step Relay Manual
This manual describes the 20 series modular step relays, available in 1‑pole, 2‑pole and double‑pole configurations with 16 A contacts. It lists the selectable switching sequences, coil options (AC and DC), contact materials and mounting options for 35 mm rail (EN 50022).
Technical specifications such as rated current, voltage, coil nominal voltages, protection rating (IP20) and mechanical/electrical life are detailed, along with wiring diagrams, accessory modules for illuminated push‑buttons, and ordering codes.
Covers: Features · Contact specification · Coil specification · Technical data · Ordering information · Wiring diagrams
Phidgets 20 Amp Current Sensor AC/DC User Manual
The 20 Amp Current Sensor AC/DC measures up to 20 A AC and –20 A to +20 A DC, offering separate ratiometric outputs for AC and DC components. It is a ratiometric sensor designed for use with PhidgetInterfaceKit and PhidgetTextLCD devices.
The manual explains hardware installation, connection of the sensor cable to a PhidgetInterfaceKit, software setup on Windows or Mac OS X, and how to interpret sensor values using provided formulas. Detailed device specifications, connector pinouts, and alternative interface options are also included.
Covers: Product Features · Installation · Testing Procedure · Technical Information · Alternative Interface Options · Mechanical Drawing
Latest 20 manuals
20 SCFM Coalescer
The 20 SCFM Coalescer features the following specifications: 1/4” port size, NPT, BSPT, BSPP thread styles, 20 SCFM flow capacity at 100 PSI, aluminum and polycarbonate bowl types, 175°F, 200 PSIG maximum temperature and pressure, 0.01 micron and larger filter capacity, less than 1.5 PSID differential pressure, and manual drain, float drain, and float drain with indicator drain options.
KeXey 20 Modular Step Relay Manual
User Manual 4 pages · 85 KB · ENThe KeXey 20 series modular step relay manual provides features, technical data, wiring diagrams and ordering information for 16 A relays.
Phidgets 20 Amp Current Sensor AC/DC User Manual
User Manual 7 pages · 1.2 MB · ENThe Phidgets 20 Amp Current Sensor AC/DC manual provides specifications, installation steps, testing procedures, and wiring details.
20 WIDE LCD MONITOR Manual
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in 20 manuals
What is the rated current of the 20 series step relay?
The relay is rated for 16 A continuous current with a maximum peak current of 30 A.
What coil voltage options are available for the 20 series relay?
Coil voltages are offered at 8, 12, 24, 48, 110, 120, 230 and 240 V (both AC and DC versions).
What current range can the sensor measure for AC and DC?
It measures up to 20 A AC and between –20 A and +20 A DC.
