Featured ZYDMS-51 manuals
ZYDMS-51 Three-Coordinate Measuring Digital Display User Manual
The ZYDMS-51 is a compact, high‑precision three‑coordinate measuring digital display designed for length and angle position detection in various fields. It offers rich interfaces, optional RS232 communication, and an eight‑digit display with sign indication.
This manual describes the product’s features, physical dimensions, connector signal definitions, and detailed operating procedures, including how to reset, zero the axes, and start measurement using the dedicated keys. This manual is written in Chinese.
Covers: Features · Applications · Physical Dimensions · Interface Signal Definitions · Operation · Key Functions
Latest ZYDMS-51 manuals
ZYDMS-51 Three-Coordinate Measuring Digital Display User Manual
User Manual 3 pages · 144 KB · ZHThe ZYDMS-51 manual explains features, interface definitions, operation steps, and key functions of the three‑coordinate measuring digital display.
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in ZYDMS-51 manuals
How do I reset the ZYDMS-51?
Press the “复位” (Reset) key; it performs a system reset and also acts as an emergency stop when the device is running.
From: ZYDMS-51 Three-Coordinate Measuring Digital Display User Manual
How can I set the current position to zero for each axis?
After powering on, press the X0, Y0, and Z0 keys; the displayed values are cleared and the current encoder position becomes the zero point.
From: ZYDMS-51 Three-Coordinate Measuring Digital Display User Manual
