West models by category
Featured West manuals
West 6400 1/16 DIN Program Controller Manual
The West 6400 is a compact 1/16 DIN program controller (48 mm × 48 mm) featuring PID, RaPID and manual tuning, up to three output channels and Modbus communication. It can store four programs, each with up to 16 segments, and supports delay times up to 89 h 59 min.
The controller operates from a 100‑240 VAC supply (7.5 VA, 50/60 Hz), offers RS485 (1200‑9600 baud) Modbus interface, IP66 protection, and outputs rated at 2 A / 240 VAC. Temperature range is 0 °C‑55 °C with 20 %‑95 % relative humidity. LED indicators show status of programs, events and alarms. This manual is written in Chinese.
Covers: Features · Program Structure · Operation · Inputs and Outputs · Dimensions · Power Supply
Latest West manuals
West 6600 1/16 DIN Plastics Controller Manual
Siemens West 6600 1/16 DIN Plastics Controller provides high quality control in applications requiring a heater break function or soft-start for process warm up. Heater current can also be displayed, removing the need for a separate ammeter.
WEST INSTRUMENTS West 6500 1/16 DIN Simplified Temperature Controller handbook
The West 6500 temperature controller features a simplified operator interface and automatic self-tuning on process start-up
WEST INSTRUMENTS P6010 handbook
The West P6010 1/16 Din Panel Indicator features multi-point scaling, tare function, and improved flexibility. It has a universal input and is available with a red or green display. Plug-in modules allow up to four alarm relays, PV retransmission, or transmitter power supply.
West 6400 1/16 DIN Program Controller Manual
User Manual 8 pages · 1.6 MB · ZHThe West 6400 1/16 DIN program controller manual provides specifications, wiring options, and operation instructions for the controller.
WEST WestP80101/8DIN digital display Manual
Which document do I need?
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in West manuals
How many programs can the West 6400 store?
The controller can store up to four programs.
What communication protocol does the controller use?
It communicates via Modbus over an RS485 interface (1200‑9600 baud).
