天津品创科技发展有限公司 Manuals

Key facts

Manuals: 3
Languages: ZH
Last added: 2026-09-30

Featured 天津品创科技发展有限公司 manuals

Tianjin Pinchuang SYJ-800 CNC Slicing Cutting Machine Manual

User Manual 4 pages · 220 KB · ZH

The SYJ-800 CNC slicing cutting machine is designed for slicing and cutting thin sheet materials such as crystal, ceramic, glass, mineral, and metal. It offers a maximum slice diameter of 200 mm, cutting precision of 0.02 mm, and computer‑controlled 3‑D automation, making it suitable for laboratory and production environments.

Key features include a 3000 rpm DC spindle motor with speed control from 300‑3000 rpm, a 360° rotating table with ±0.01° tolerance, an 8‑inch precision vacuum chuck for 200 mm wafers, and waterproof splash protection with adjustable cutting‑fluid flow. Technical parameters, standard accessories, optional accessories, and machine dimensions are detailed in the manual. This manual is written in Chinese.

Covers: Product Overview · Key Features · Technical Specifications · Standard Accessories · Optional Accessories · Product Dimensions

Tianjin Pinchuang GZK-101 Vacuum Unit User Manual

User Manual 4 pages · 145 KB · ZH

The GZK-101 is a low‑vacuum unit designed by Tianjin Pinchuang Technology Development Co., Ltd. It features a dual‑rotor mechanical pump (TRP‑12), KF‑D25 interface, high‑vacuum flange, digital vacuum gauge (CVM‑211) and various pipe fittings. The unit complies with CE certification.

Key technical data include a 220 V 50/60 Hz power supply, 550 W pump motor, 4 L/s pumping speed, and a maximum pressure of 6.7×10⁻⁴ mbar. The chassis measures 600 mm × 600 mm × 600 mm, supports up to 1000 lbs, and contains a 1000 ml oil tank. Standard accessories such as stainless‑steel wave‑type hoses, clamps, and KF‑25 fittings are supplied. This manual is written in Chinese.

Covers: Product Overview · Technical Parameters · Standard Accessories · Dimensions and Weight · Certifications

Tianjin Pinchuang VTC-2D DC Plasma Magnetron Sputtering Coating System User Manual

User Manual 7 pages · 274 KB · ZH

The VTC-2D is a small‑scale DC plasma magnetron sputtering coating instrument designed for laboratory metal‑film deposition. It includes a 500 W/600 V DC power supply, a 2‑inch water‑cooled sputtering head, a quartz vacuum chamber, a vacuum pump, and a temperature controller. Optional accessories such as a 1‑inch sputtering head and a molecular pump are available.

The system features a rotatable, heated sample stage (diameter 50 mm, up to 2‑inch substrates) with rotation speeds of 1‑10 rpm and a maximum temperature of 700 °C (±1.0 °C). A quartz‑vibrating film thickness monitor provides real‑time thickness measurement with 0.10 Å resolution. Safety notes advise using high‑purity inert gases (>5N) and optional gas‑purification or RF power for non‑conductive targets. This manual is written in Chinese.

Covers: Product Overview · Plasma Source · Magnetron Sputtering Head · Sample Stage · Vacuum Pump · Film Thickness Monitor

Latest 天津品创科技发展有限公司 manuals

Tianjin Pinchuang SYJ-800 CNC Slicing Cutting Machine Manual
User Manual 4 pages · 220 KB · ZH
The SYJ-800 CNC slicing cutting machine manual provides product overview, technical specifications, and operating instructions for precision cutting of…
Tianjin Pinchuang GZK-101 Vacuum Unit User Manual
User Manual 4 pages · 145 KB · ZH
The Tianjin Pinchuang GZK-101 vacuum unit manual provides specifications, features, and operating guidelines for the low‑vacuum system.
Tianjin Pinchuang VTC-2D DC Plasma Magnetron Sputtering Coating System User Manual
User Manual 7 pages · 274 KB · ZH
The Tianjin Pinchuang VTC-2D is a compact DC plasma magnetron sputtering coating system with integrated power supply, sputtering head, vacuum pump and…
