Featured Dilong manuals
Dilong DEM/DSM/DBM/DQM Series Brick Power Module Typical Application
The note describes the recommended input side components for the brick‑type modular power supplies, including input fuses, transient‑voltage‑suppressor diodes, filter capacitors, common‑mode and differential‑mode inductors, and output filtering capacitors. It also gives layout advice such as using wide copper traces and placing output capacitors close to the module to reduce interference.
Remote control (REM) operation and output voltage adjustment (TRIM) are explained. REM uses voltage‑controlled logic (high or low level) to turn the supply on or off, while the TRIM pins allow the output voltage to be fine‑tuned with external resistor networks or potentiometers, supporting both positive and negative logic modes. This manual is written in Chinese.
Covers: Input Side Fuse and Protection · Input Filter Capacitors and Inductors · Output Filtering and Capacitors · Remote Control (REM) Operation · TRIM Output Voltage Adjustment · Typical Application Circuits
Dilong DLR500-24S220 Pure Sine Wave Inverter User Manual
This manual describes the Dilong DLR500-24S220 inverter, which uses an intelligent IC control circuit with multiple protection functions such as overload, over‑current, high‑temperature, short‑circuit, reverse‑polarity, and battery voltage protection. The output is a pure sine wave suitable for any load, and the unit is compact and portable.
The document covers connection methods, input power requirements, technical specifications, protection and status indicator details, operating environment, physical dimensions, safety precautions, and a troubleshooting guide for common fault conditions. This manual is written in Chinese.
Covers: Preface · Operation · Input Power Requirements · Technical Specifications · Protection Features · Status Indicators
Dilong DZA1500SD Series Power Module Datasheet
The DZA1500SD series power modules from Dilong are designed for industrial, military and aerospace applications. The document provides detailed technical parameters such as input and output voltages, current ratings, efficiency, and protection features.
Key highlights include high efficiency (>85%), wide input voltage range (AC220 165‑264 V, AC180 90‑264 V), robust protection (over‑current >120 %, over‑temperature self‑recovery at 90 °C), and strong environmental performance (MTBF 500 000 h, natural cooling). This manual is written in Chinese.
Covers: Technical Parameters · Input Voltage · Output Current · Efficiency · Protection Features · Environmental Ratings
Dilong DZE500S Power Module Datasheet
This document provides the detailed technical parameters of the Dilong DZE500S power module. It lists the supported input voltage ranges, output power of 500 W, efficiency greater than 85 %, voltage accuracy, load regulation, dynamic response, and various protection features such as over‑current and over‑temperature safeguards.
Environmental and mechanical specifications are also included, describing operating temperature limits for industrial, military and aerospace grades, humidity ranges, vibration and shock resistance, natural cooling method, isolation voltage, and MTBF information. The module is designed for high‑reliability applications in industrial, military and aerospace fields. This manual is written in Chinese.
Covers: Input Voltage · Output Power · Efficiency · Protection Features · Environmental Ratings · Mechanical Design
Latest Dilong manuals
Dilong DEM/DSM/DBM/DQM Series Brick Power Module Typical Application
Application Note 3 pages · 166 KB · ZHThis document shows typical application circuits and usage instructions for Dilong's DEM/DSM/DBM/DQM series brick power modules.
Dilong DLR500-24S220 Pure Sine Wave Inverter User Manual
User Manual 3 pages · 161 KB · ZHThe Dilong DLR500-24S220 pure sine wave inverter user manual provides specifications, operation instructions, protection features, and troubleshooting.
Dilong DZA1500SD Series Power Module Datasheet
Datasheet 1 pages · 222 KB · ZHTechnical specifications for Dilong DZA1500SD series power modules, covering voltage ranges, efficiency, protection and environmental ratings.
Dilong DZE500S Power Module Datasheet
Datasheet 1 pages · 206 KB · ZHTechnical specifications for the Dilong DZE500S power module, covering input/output ranges, power, efficiency, protection and environmental ratings.
