Featured netvox manuals
Netvox R718PB14 Wireless Soil Volume Water Content Temperature Electrical Conductivity Sensor Datasheet
The R718PB14 is a compact wireless device for monitoring soil moisture, temperature and electrical conductivity. It transmits data via LoRa to other equipment for display and analysis.
Key features include an SX1276 LoRa module, dual ER14505 lithium batteries, IP65 rating, magnetic base for easy mounting, and support for multiple LoRaWAN frequency bands. The datasheet provides detailed electrical, RF, and sensor specifications, as well as environmental operating limits.
Covers: Overview · Main Features · Physical Dimensions · Electrical Characteristics · RF Characteristics · Antenna & Communication
Netvox RA0730/RA0730Y/R72630 Temperature Humidity Wind Speed Wind Direction Sensor User Manual
The RA0730, RA0730Y and R72630 are LoRaWAN Class A sensors that measure temperature, humidity, wind speed and wind direction. The devices use the SX1276 wireless communication module and support LoRaWAN protocol. RA0730 and RA0730Y are powered by a DC 12 V adapter, while the R72630 is powered by a solar panel and a rechargeable lithium‑ion battery.
This manual describes the physical appearance of each model, the product features, how to power on the device, reset it to factory settings, add it to a LoRaWAN network, configure reporting intervals, install the hardware (including waterproof mounting for the R72630 and RA0730Y), and recommended maintenance and care procedures. This manual is written in Chinese.
Covers: Declaration · Physical Appearance · Introduction · Product Features · Operation Instructions · Installation Method
Netvox RA0715 Wireless CO2/Temperature/Humidity Sensor Datasheet
The RA0715 wireless sensor combines a temperature‑humidity sensor and a CO₂ sensor in a single LoRa‑enabled device. It uses the SX1276 communication module and supports LoRaWAN frequency bands, allowing integration with platforms such as TTN, MyDevices, and Cayenne for smart‑home or smart‑farm applications.
Technical specifications include a 12 V DC power input, standby current of 125 mA, operating current of 40 mA, and a built‑in antenna providing up to 10 km line‑of‑sight range. The CO₂ sensor measures 400‑5000 ppm with ±100 ppm+6% accuracy, while temperature is measured from –20 °C to 55 °C with ±0.5 °C accuracy and humidity from 0 %RH to 100 %RH with ±4 %RH accuracy.
Covers: Introduction · Main Features · Electrical Input Power · CO₂ Sensor Specifications · Temperature and Humidity Sensor · Frequency and Modulation
Netvox R718N163 Wireless Single-Phase Current Detector Data Sheet
The Netvox R718N163 wireless single‑phase current detector measures AC line current via an external current transformer and reports the data over LoRaWAN to a gateway for cloud‑based monitoring. It is battery‑powered, supports long‑term deployment, and can be integrated with third‑party IoT platforms.
Key features include a SX1276 LoRa module, dual ER14505 Li‑ion batteries (3.6 V, 2400 mAh each) with an estimated 5‑year life, IP53/IP30 protection, built‑in antenna, and configurable parameters via third‑party software. Electrical specifications cover a measurement range of 5 A–630 A, ±1 % accuracy, 1 mA resolution, and RF performance up to 19 dBm output power. This manual is written in Chinese.
Covers: Overview · Dimensions · Electrical Characteristics · RF Characteristics · Current Transformer Parameters
Latest netvox manuals
Netvox R718PB14 Wireless Soil Volume Water Content Temperature Electrical Conductivity Sensor Datasheet
Datasheet 5 pages · 558 KB · ENThe Netvox R718PB14 is a wireless sensor that measures soil water content, temperature and electrical conductivity, featuring IP65 protection and LoRa…
Netvox RA0730/RA0730Y/R72630 Temperature Humidity Wind Speed Wind Direction Sensor User Manual
User Manual 7 pages · 1.4 MB · ZHThe Netvox RA0730/RA0730Y/R72630 sensor manual provides setup, operation, installation, and maintenance instructions for temperature, humidity, wind speed…
Netvox RA0715 Wireless CO2/Temperature/Humidity Sensor Datasheet
Datasheet 5 pages · 229 KB · ENThe Netvox RA0715 is a LoRa‑based wireless sensor that measures temperature, humidity and CO₂ with up to 10 km range.
Netvox R718N163 Wireless Single-Phase Current Detector Data Sheet
Datasheet 5 pages · 309 KB · ZHThe Netvox R718N163 is a LoRa‑WAN compatible wireless single‑phase current detector with low power consumption and detailed electrical specifications.
Netvox Z809AH Wireless Measurement and Switch Socket Datasheet
Datasheet 4 pages · 159 KB · ZHThe Netvox Z809AH datasheet details a ZigBee‑compatible indoor smart socket with power measurement, switch control, and wireless communication specs.
Which document do I need?
Datasheet
Ratings, dimensions and ordering codes, for selection and design work.
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in netvox manuals
What is the communication range of the R718PB14?
The device can transmit up to 10 km in clear line‑of‑sight, with actual distance depending on the environment.
What power source does the sensor use?
It is powered by two ER14505 lithium batteries (3.6 V, 2400 mAh each) connected in parallel.
How do I reset the device to factory settings?
Press and hold the button for 5 seconds; the green LED will flash rapidly 20 times, indicating the device has been restored to factory settings.
From: Netvox RA0730/RA0730Y/R72630 Temperature Humidity Wind Speed Wind Direction Sensor User Manual
How can I add the sensor to a LoRaWAN network?
Power the device on; it will search for a network. A solid green LED for 5 seconds indicates successful network joining.
From: Netvox RA0730/RA0730Y/R72630 Temperature Humidity Wind Speed Wind Direction Sensor User Manual
What wireless technology does the RA0715 use?
It uses the SX1276 wireless communication module and supports LoRa technology.
From: Netvox RA0715 Wireless CO2/Temperature/Humidity Sensor Datasheet
What is the CO₂ measurement range of the sensor?
The CO₂ sensor measures concentrations from 400 ppm to 5000 ppm.
From: Netvox RA0715 Wireless CO2/Temperature/Humidity Sensor Datasheet
