Belling models by category
Featured Belling manuals
Belling BL0937 Smart Socket Metering Chip Application Guide
The BL0937 is a compact SOP‑8 chip designed for energy measurement in smart‑socket applications. It offers a wide measurement range, low power consumption and simple external circuitry.
The document provides detailed pin descriptions, calibration procedures, formulas for converting pulse frequencies to power, a parts list and practical PCB layout recommendations to ensure accurate measurements and reliable operation. This manual is written in Chinese.
Covers: Chip Features · Pin Description · Calibration · Energy Measurement · Bill of Materials · PCB Design Guidelines
Belling BL0937 Single-Phase Socket Metering Chip Datasheet
The BL0937 is a single‑phase metering IC designed for smart sockets, power strips and other single‑phase appliance control circuits. It integrates two high‑precision sigma‑delta ADCs, reference voltage, power‑management circuits and digital signal processing to output voltage and current RMS values as high‑frequency pulses.
The document provides pin definitions, electrical parameters, typical application circuits, calibration guidance and a BOM. Key features include a 3.3 V supply, SOP‑8 package, built‑in 1.218 V reference, anti‑drift design, and fast over‑current detection with a 6.78 kHz pulse output. This manual is written in Chinese.
Covers: Features · Pin Definition · Electrical Parameters · Working Principle · Typical Application · Over‑Current Detection
Belling BL6501A Energy Measurement Chip Datasheet
The BL6501A is a single‑phase dual‑current sampling energy‑measurement IC designed for electronic electricity meters. It offers high accuracy, low power consumption, and built‑in anti‑theft features such as REVP and FAULT output pins.
The document provides a full pin description, electrical parameters, timing characteristics, mode and gain selection tables, and typical application circuits. It also includes package dimensions and operating temperature range. This manual is written in Chinese.
Covers: Features · Pin Description · Electrical Parameters · Timing Characteristics · Operation Principle · Mode Selection
Latest Belling manuals
Belling BL0937 Smart Socket Metering Chip Application Guide
Application Note 5 pages · 674 KB · ZHThis guide explains the BL0937 chip's features, pinout, calibration method, energy‑measurement principle, BOM and PCB design tips.
Belling BL0937 Single-Phase Socket Metering Chip Datasheet
Datasheet 12 pages · 972 KB · ZHThe BL0937 is a high‑accuracy, low‑power single‑phase energy‑measurement IC with built‑in 2 MHz clock, anti‑drift design and over‑current detection.
Belling BL6501A Energy Measurement Chip Datasheet
Datasheet 11 pages · 419 KB · ZHThe Belling BL6501A datasheet details specifications, pin functions, and performance of this single‑phase dual‑current sampling energy measurement chip.
Which document do I need?
Application Note
How to use the product for one specific task, with worked examples.
Datasheet
Ratings, dimensions and ordering codes, for selection and design work.
Questions answered in Belling manuals
How should the BL0937 be calibrated?
Use a single‑point calibration: apply a rated voltage and current, measure the corresponding CF, CF1 and P pulse frequencies, then compute voltage, current and power conversion coefficients (Ku, Ki, Kp) for use in the system software.
From: Belling BL0937 Smart Socket Metering Chip Application Guide
What does the CF1 pin output?
CF1 provides an active‑power high‑frequency pulse with a fixed 38 µs width; its frequency is proportional to the measured power, and it also indicates over‑current with a 6.78 kHz pulse.
From: Belling BL0937 Smart Socket Metering Chip Application Guide
What supply voltage range does the BL0937 require?
The chip operates with VDD between 3.0 V and 3.6 V.
From: Belling BL0937 Single-Phase Socket Metering Chip Datasheet
How is over‑current indicated by the BL0937?
When an over‑current condition occurs, the CF pin outputs a 6.78 kHz pulse.
From: Belling BL0937 Single-Phase Socket Metering Chip Datasheet
What is the typical power consumption of the BL6501A?
The chip consumes about 15 mW under typical conditions.
