Featured Ai-Thinker manuals
Ai-Thinker BG02 GNSS SoC Module Datasheet
BG02 is a highly integrated GNSS SoC module featuring multi‑GNSS support, DC/DC, LDO, LNA, RF front‑end, baseband, a 32‑bit RISC CPU, RAM, flash, RTC and PMU, with UART, I2C, SPI and GPIO interfaces. The module is offered in several sub‑models that differ in supported constellations.
The datasheet includes sections on product overview, electrical specifications, mechanical dimensions, pin assignments, schematic diagram, design recommendations, reflow solder profile, packaging details and contact information for support and sales. This manual is written in Chinese.
Covers: Product Overview · Electrical Parameters · Physical Dimensions · Pin Definitions · Schematic Diagram · Design Guidance
Ai-Thinker BW16 Wi‑Fi Bluetooth SoC Module Datasheet
The BW16 is a dual‑frequency Wi‑Fi and Bluetooth 5.0 SoC module based on the RTL8720DN chip. It integrates an ARM‑V8 MCU (Cortex‑M4F), a low‑power ARM‑V8M MCU (Cortex‑M0), Wi‑Fi (802.11a/b/g/n), MAC, Bluetooth baseband, RF baseband and a set of configurable GPIO ports for peripheral control.
The document includes sections on product overview, electrical parameters, appearance size, pin definition, schematics, design guidelines, reflow profile, packaging information and contact details, offering developers the data needed for hardware design and integration. This manual is written in Chinese.
Covers: Product Overview · Electrical Parameters · Appearance Size · Pin Definition · Schematics · Design Guidelines
Ai-Thinker ESP8266 WiFi Module User Manual
This manual introduces the ESP8266, a low‑power UART‑WiFi transceiver designed for IoT applications. It describes the module’s features, packaging options, and typical use cases such as smart grids, transportation, and industrial control.
The document covers hardware interfaces, power consumption, RF performance, pin definitions, and a full set of AT commands for Wi‑Fi, TCP/UDP, and configuration. It also includes a test board overview and information on firmware upgrades and OTA updates. This manual is written in Chinese.
Covers: Terminology and Abbreviations · Product Overview · Hardware Introduction · Power Consumption · RF Specifications · Dimensions
Ai Thinker A6/A7/A6C Module User Manual
This manual covers the main specifications of the Ai Thinker A6, A7 and A6C modules, including dimensions, operating temperature, voltage ranges, supported GSM/GPRS bands, data rates, and certifications. It also details the hardware interfaces such as UART ports, GPIO levels, and camera connections.
Detailed pin‑out tables for each module version are provided, along with the AT commands needed to control power, low‑power mode, GPS/AGPS activation, and data transmission. The document includes notes on hardware design examples and references to the optional breakout boards. This manual is written in Chinese.
Covers: Main Specifications · A6 Module Overview · A6 Pin Description · A7 Module Overview · A7 AT Commands · A6C Module Overview
Latest Ai-Thinker manuals
Ai-Thinker BG02 GNSS SoC Module Datasheet
Datasheet 14 pages · 864 KB · ZHThe Ai-Thinker BG02 GNSS SoC Module datasheet provides electrical parameters, dimensions, pin definitions, and design guidelines.
Ai-Thinker BW16 Wi‑Fi Bluetooth SoC Module Datasheet
Datasheet 15 pages · 787 KB · ZHThe Ai‑Thinker BW16 datasheet provides specifications, pin definitions, electrical parameters and design guidelines for the dual‑frequency Wi‑Fi/Bluetooth…
Ai-Thinker ESP8266 WiFi Module User Manual
User Manual 31 pages · 1 MB · ZHThe Ai-Thinker ESP8266 WiFi Module User Manual provides an overview, hardware details, AT command reference, and specifications for the module.
Ai Thinker A6/A7/A6C Module User Manual
User Manual 20 pages · 1.3 MB · ZHThe Ai Thinker A6/A7/A6C Module User Manual provides specifications, pin descriptions, and AT command usage for GSM/GPRS and GPS/AGPS functions.
Which document do I need?
Datasheet
Ratings, dimensions and ordering codes, for selection and design work.
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in Ai-Thinker manuals
What is the operating temperature range of the BG02 module?
The module operates from –40 °C to 85 °C.
What supply voltage does the BG02 support?
It accepts a supply voltage between 3.0 V and 3.6 V.
How many interface pins does the BW16 have?
The module provides 16 interface pins.
What are the physical dimensions of the BW16 package?
The package measures 24 mm × 16 mm × 3 mm (±0.2 mm).
How do I set the Wi‑Fi operating mode?
Use the AT+CWMODE command to select STA, AP, or STA+AP mode.
What is the standby current consumption of the ESP8266?
The module draws less than 200 µA in standby.
