Featured Probe Set manuals
A+ Corporation 755 Installation & Operation Instructions
This guide provides safety warnings, required tools, and detailed installation steps for the Genie® Direct Drive 755 probe. It covers valve selection, probe depth setting, leak testing, and pressure adjustment to ensure proper operation.
Technical specifications such as maximum pressure rating, temperature range, material construction, and available probe lengths are listed, along with part numbers for spare parts and accessories.
Covers: Safety Warnings · Required Tools and Fittings · Technical Specifications · Installation Procedure · Leak Testing · Setting Outlet Pressure
Tektronix ABC Probe Introductory Manual
This manual introduces the fundamentals of Tektronix ABC probes, explaining what a probe is, ideal characteristics, and real‑world limitations. It also provides safety guidelines for handling probes and preventing damage to equipment or personnel.
The guide walks users through probe selection, including how to match probes to signal sources and oscilloscopes, and discusses the effects of probe capacitance, bandwidth, and loading on measurement accuracy. Advanced topics such as differential measurement, floating measurements, and ground‑lead considerations are also covered. This manual is written in Chinese.
Covers: What is a probe? · Ideal probe characteristics · Actual probe characteristics · Probe selection guide · Understanding signal source and oscilloscope · Probe impact on measurement
Fujitsu PB-91467D-NLS-208PFV Probe Cable User Guide for MB91V460 Family
The guide describes the PB-91467D-NLS-208PFV probe cable, which connects the MB2198-300 with a MB91F467D target board. It features a 120 mm flexible section and shielded analogue signals, and is intended for use in an evaluation laboratory environment.
The document covers default jumper settings, installation steps, dimensions, warranty and disclaimer, regulatory information, and recycling instructions, helping users correctly set up and maintain the cable.
Covers: Overview · Default Jumper Setting · Jumpers · Installation · Dimensions · Warranty and Disclaimer
Infinet OIHVP15HF / OIHVP40 High Voltage Probe User Manual
The OIHVP15HF and OIHVP40 are high‑voltage probes designed for use with oscilloscopes to measure up to tens of kilovolts safely. The manual details the electrical characteristics, cable length, and environmental limits for each model.
Key sections cover safety precautions such as grounding the probe before contact, turning off the high‑voltage source when possible, and proper cleaning. Operational steps describe connecting the probe to the oscilloscope, selecting the appropriate voltage range, and interpreting the divided voltage reading. This manual is written in Chinese.
Covers: Specifications · Safety Precautions · Operation · Cleaning · Warnings · Technical Data
Latest Probe Set manuals
A+ Corporation 755 Installation & Operation Instructions
Installation Guide 4 pages · 1.1 MB · ENInstallation and operation guide for the Genie® Direct Drive 755 probe, including safety warnings, specifications, and step‑by‑step procedures.
Tektronix ABC Probe Introductory Manual
User Manual 60 pages · 2 MB · ZHAn introductory guide covering probe basics, safety, selection, and measurement impact for Tektronix ABC probes.
Fujitsu PB-91467D-NLS-208PFV Probe Cable User Guide for MB91V460 Family
User Manual 16 pages · 440 KB · ENThis Fujitsu user guide provides installation, jumper settings, dimensions, and warranty information for the PB-91467D-NLS-208PFV probe cable used with…
Infinet OIHVP15HF / OIHVP40 High Voltage Probe User Manual
User Manual 12 pages · 167 KB · ZHThe Infinet OIHVP15HF and OIHVP40 high‑voltage probe user manual provides specifications, safety precautions, and operating instructions.
Which document do I need?
Installation Guide
Mounting, wiring and first power-up. Read it before the hardware goes in.
User Manual
Day-to-day operation, settings and troubleshooting. Start here if the product is already set up.
Questions answered in Probe Set manuals
What tools are required to install the Genie Direct Drive 755 probe?
You need a 1‑3/8” open‑end wrench, a 7/16” open‑end wrench, two 7/8” open‑end wrenches, and a 1‑3/16” open‑end wrench for specific steps.
From: A+ Corporation 755 Installation & Operation Instructions
What is the recommended bandwidth rule for accurate amplitude measurements?
The oscilloscope bandwidth should be at least five times higher than the highest frequency component of the signal.
What is the default setting for jumper JP2?
JP2 (VCC3C) is set to closed (ON) connecting VCC3C to 10 µF | 10 nF → GND.
From: Fujitsu PB-91467D-NLS-208PFV Probe Cable User Guide for MB91V460 Family
What is the division ratio of the OIHVP15HF probe?
The OIHVP15HF probe has a division ratio of 1000:1.
From: Infinet OIHVP15HF / OIHVP40 High Voltage Probe User Manual
What is the maximum working voltage of the OIHVP40 probe?
The OIHVP40 can handle up to 40 kV DC or peak AC, and 28 kV rms AC.
From: Infinet OIHVP15HF / OIHVP40 High Voltage Probe User Manual
